Honeywell Servo motors B5-5S1 LKS120-02

SKU LKS120-02 Model B5-5S1 Brand Honeywell

Photos

Key specifications

Supply voltage	230 V
Torque, Nm	75 Nm
Installation	through holes for m5*50 m
Electrical connection	5-pole terminal block
Maintenance requirement	maintenance-free
Body material	synthetic
Protection class (IP)	IP31
Power consumption	9 W
Construction type	synchronous motor with gearboxes

all specifications (9) ↓

552.23 EUR

502.03EUR

in stock · 15

incl. 21% VAT · 414.90 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This servo motor is designed for use in single-stage and two-stage burners with or without a fully closing flap. The drive unit consists of a synchronous motor with gearboxes enclosed in a synthetic housing. It is powered by 230 V and consumes 9 W, delivering a torque of 75 Nm. The unit has IP31 protection and connects via a 5-pole terminal block. It is maintenance-free and is installed using through holes for M5*50 screws.

All specifications

Supply voltage	230 V
Torque, Nm	75 Nm
Installation	through holes for m5*50 m
Electrical connection	5-pole terminal block
Maintenance requirement	maintenance-free
Body material	synthetic
Protection class (IP)	IP31
Power consumption	9 W
Construction type	synchronous motor with gearboxes

Part numbers

SKU	LKS120-02
Additional article	534.712.002
Model	B5-5S1
