Honeywell Servo motors B5-5S1 LKS120-10

SKU LKS120-10 Model B5-5S1 Brand Honeywell

Photos

Key specifications

Supply voltage	230 V
Torque, Nm	75 Nm
90° opening time	5 seconds
Installation	through holes for m5*50 m
Electrical connection	5-pole terminal block
Weight	500 g
Body material	synthetic materials
Protection class (IP)	IP31
Power consumption	9 W
Ambient temperature	-10 °C
Construction type	synchronous motor with gearboxes
Design features	compact dimensions

all specifications (12) ↓

364.64 EUR

331.49EUR

in stock · 2

incl. 21% VAT · 273.96 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This servo motor is a synchronous motor with gearboxes, intended for use in burners with single-stage or two-stage control systems, with or without a closing flap. It operates on 230 V supply and draws 9 W. The unit provides 75 Nm torque and completes a 90° opening in 5 seconds. The housing is made of synthetic materials and has protection class IP31. The design has compact dimensions. Electrical connection uses a 5-pole terminal block; mounting is through holes for M5 × 50 screws.

Further details

Application type	burners with a single-stage or two-stage control system

All specifications

Supply voltage	230 V
Torque, Nm	75 Nm
90° opening time	5 seconds
Installation	through holes for m5*50 m
Electrical connection	5-pole terminal block
Weight	500 g
Body material	synthetic materials
Protection class (IP)	IP31
Power consumption	9 W
Ambient temperature	-10 °C
Construction type	synchronous motor with gearboxes
Design features	compact dimensions

Part numbers

SKU	LKS120-10
Additional article	534.712.004
Model	B5-5S1
