ACV Anode 90021033

SKU 90021033 Brand ACV

Photos

Key specifications

Length	270 mm
Width	32 mm
Body material	magnesium
Replacement interval	1-2 years
Includes gasket	glass gasket
Included components	glass gasket
Anode type	magnesium sacrificial anode
Consumable	yes
material	magnesium
Size	32x270 mm
Design features	easy installation without special tools

all specifications (11) ↓

44.19 EUR

40.17EUR

in stock · 2

incl. 21% VAT · 33.20 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This is a magnesium sacrificial anode sized 32x270 mm, intended for ACV boilers and water heaters. It protects the internal steel cylinder from corrosion by attracting corrosive elements and degrading instead of the tank wall. The kit includes a glass gasket to ensure a tight seal. The recommended replacement interval is 1-2 years, depending on water hardness. It fits ACV 150, 200, and 300 series units. Installation requires no special tools.

Further details

Application	Boilers and storage tanks with enamelled cylinders
Mounting requirement	anode must match original mounting thread, length, and head shape to fit cylinder boss
Protection purpose	internal surfaces of boilers and water heaters

Choosing and fitting

Anodes of this type are selected by matching the mounting thread, length, and head shape to the cylinder boss of the boiler or tank. Before ordering, measure the old anode's thread and length to ensure compatibility. The mounting surface must be clean to guarantee electrical contact for corrosion protection. Installation usually requires no special tools.

Signs of failure

Sacrificial anodes are depleted over time as they corrode in place of the tank. A consumed anode may appear reduced in diameter, pitted, or crumbly. If it is not replaced, the tank's corrosion protection is lost, leading to rust and potential damage. Routine service checks will reveal a worn anode that needs replacement.

Fits equipment

ACV 150ACV 200ACV 300ACV 150 seriesACV 200 seriesACV 300 series

All specifications

Length	270 mm
Width	32 mm
Body material	magnesium
Replacement interval	1-2 years
Includes gasket	glass gasket
Included components	glass gasket
Anode type	magnesium sacrificial anode
Consumable	yes
material	magnesium
Size	32x270 mm
Design features	easy installation without special tools

Part numbers

SKU	90021033
Additional article	129.112.001
