ACV Gasket fan 557A0054
SKU 557A0054
Brand ACV
Photos
Key specifications
| Catalogue article numbers | 557A0054, 129.862.007 |
|---|---|
| Interchangeability | not interchangeable with other variants |
| Maintenance requirement | routine consumables |
15.02 EUR
13.65EUR
in stock · 3
incl. 21% VAT · 11.28 EUR excl. VAT · shipping calculated at checkout
- Worldwide shipping from stock
- Original manufacturer part
- Dispatch within 24 h for stocked items
Description
ACV Gasket fan 557A0054 is a gasket for the fan assembly on ACV Prestige, HeatMaster 60, HeatMaster 85, Prestige 24 MK2, Prestige 32 MK2, and CA 200 Compact boilers. It creates a sealed joint between the fan outlet and the mating surface on the burner or boiler casing, preventing combustion air leaks and flue gas recirculation. This gasket is a routine consumable, replaced whenever the fan is removed for cleaning or inspection. It is identified by SKU 557A0054 and article numbers 557A0054 and 129.862.007, and is not interchangeable with other variants.
Further details
| Benefits | pressure & heat resistance, factory-grade materials, leak-free operation |
|---|---|
| Compatible With | Heatmaster 60, Heatmaster 85, Prestige 24 mk2, Prestige 32 mk2, CA 200 Compact |
| Failure consequence | reduce pressure differential, cause nuisance lockouts or failure to start |
| Function | create a sealed joint between the fan outlet and the mating surface on the burner or boiler casing |
| Installation requirement | confirm that the new gasket matches the original in thickness and shape |
| Kit contents | single gasket, not a multi-gasket kit |
| Material requirements | resist temperatures and media, typically ambient air, slight positive pressure, occasional heat radiation |
| Selection criteria | exact outer dimensions, bolt hole pattern, and material |
Choosing and fitting
Parts of this type are selected by matching the exact outer dimensions, bolt hole pattern, and material to the original gasket. Confirm the new gasket matches the original in thickness and shape, as a compressed or mismatched gasket can alter fan alignment or disturb the air pressure switch signal. Install the gasket between the fan outlet and the mating surface, ensuring a proper seal before reassembling the fan.
Signs of failure
When gaskets of this kind fail, they may leak, reducing the pressure differential that the air pressure switch relies on to prove airflow. This can cause nuisance lockouts or a failure to start. Check the gasket for cracks, compression, or deformation when the fan is removed for service.
Fits equipment
ACV Prestige HeatMaster 60 HeatMaster 85 Prestige 24 MK2 Prestige 32 MK2 CA 200 CompactACV Heatmaster 60ACV Heatmaster 85ACV Prestige 24 mk2ACV Prestige 32 mk2ACV CA 200 Compact
All specifications
| Catalogue article numbers | 557A0054, 129.862.007 |
|---|---|
| Interchangeability | not interchangeable with other variants |
| Maintenance requirement | routine consumables |
Part numbers
| SKU | 557A0054 |
|---|---|
| Additional article | 129.862.007 |
