Riello Cable 3006294

Riello Cable 3006294 is a complete assembly kit for restoring the electrical circuit in Riello gas boilers. The cable has heat and oil resistant insulation and precise pin assignment for correct connection. It carries low-voltage control signals or mains supply between the burner control board and system components such as the gas valve, ignition transformer, fan, or flame detector.

Parts of this type are selected by matching the connector series, pin count, and keying to the sockets on the control board and the component. Additional selection criteria include conductor cross-section, insulation temperature class, overall length, and terminal type (flag, ring, or pin terminals). Before ordering, verify that the connector form and pin arrangement match the existing component and control board. Inspect both connector halves for corrosion, bent pins, or damaged seals.

Faults of this kind of cable typically arise from poor contact in connectors. Symptoms include intermittent lockouts, unstable flame signal, or components failing to energise. Corrosion, bent pins, or damaged seals in the connector halves are common failure points. Inspect both connector halves for these issues.
