Siemens Terminal block / plug-in base AGM14.1

SKU AGM14.1 Brand Siemens

Photos

Key specifications

Connection thread	M16
Length	103 mm
Width	103 mm
Height	25 mm
material	high-quality heat-resistant plastic
Connection method	Plug-in
Rated voltage	250 v
Rated current	10 a
Number of cable entries	6

all specifications (9) ↓

64.35 EUR

58.50EUR

in stock · 1

incl. 21% VAT · 48.35 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This plug-in terminal block is the connection base for Siemens LFL1.. and LFL2.. burner control units. It has six cable entries with M16 thread and a polarized socket pattern. The housing measures 103 mm by 103 mm by 25 mm and is made of heat-resistant plastic. Electrical ratings are 250 V and 10 A.

Further details

Application	Gas and oil burners of Siemens LFL series
Critical compatibility factor	Selected by control series designation and plug pattern; must match the specific control model
Electrical Connection	All field wiring connects to terminals on the base
Features	Polarized connection; convenient contact marking; protection against incorrect installation
Safety standard	EN 60335-2-102 (European standards for burner equipment)
Terminal connections	Fan, ignition transformer, gas valve or oil solenoid, pressure switches, flame detector; line supply and heat demand signal

Choosing and fitting

Terminal bases for burner controls are selected by the control series and the plug pattern; a base from one series does not fit another series. Before ordering, check the model marking on the old base and compare it with the catalogue data. This kind of base mounts directly under the control module; remove the old base, transfer the wiring to the corresponding terminals, and plug the module back into the base.

Fits equipment

Siemens LFLSiemens LFL1.., LFL2..

All specifications

Connection thread	M16
Length	103 mm
Width	103 mm
Height	25 mm
material	high-quality heat-resistant plastic
Connection method	Plug-in
Rated voltage	250 v
Rated current	10 a
Number of cable entries	6

Part numbers

SKU	AGM14.1
Additional article	884.367.007
