Brahma Control box SM191N.2 24085281

This microprocessor-based control box from Brahma is designed for automatic ignition control, flame monitoring, and safe operation of atmospheric gas burners with an intermittent cycle. It features a 5-second pre-purge time, a 10-second safety time, and a 5-second wait time. Flame detection is via an ionization electrode, and the unit includes air pressure monitoring and combustion monitoring. A manual reset lockout enforces safety in abnormal conditions. The device meets EN 298 requirements and is intended for use with gas burners from Riello, Baltur, Weishaupt, and Lamborghini, as well as heat generators from Master and Oklima.

For control boxes of this type, selection must match the exact series and type designation, supply voltage, safety and pre-purge times, and the flame detection method. Interchangeability across series within the same brand is not guaranteed, as even a different safety time creates a safety risk. Before ordering, verify that the replacement matches the original model number and the burner's wiring base or plug pattern. Check not only the codes but also the physical layout of the plug-in base and the terminal designations to ensure a direct fit.
