Honeywell Control box 0452003

SKU 0452003 Brand Honeywell

Photos

Key specifications

Supply voltage	220–240 V
Protection class (IP)	IP40
Stray light monitoring	5 sec
Weight incl. wiring base	190 kg
Fuel	gas, dual fuel
Installation position	any
Weight including base	190 g
Air proving switch	1 working contact 4 A, 230 V
Mounting position	any

all specifications (9) ↓

372.60 EUR

338.73EUR

in stock · 12

incl. 21% VAT · 279.94 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This control box supervises and controls gas and dual fuel burners. It operates on 220–240 V and has IP40 protection. It can be mounted in any position. Stray light monitoring lasts 5 seconds. The air proving switch has one working contact rated at 4 A, 230 V. Weight including the wiring base is 190 g.

Further details

Approved ambient parameter for control and flame detector	max. 95% at 30° C
Cable length	< 3 m
Min. required ion. current	1.5 μA
Protection class	IP 40
Sensitivity (operation)	1 μA
Sensitivity (operation)	1 μA
Sensitivity for stray light	0.4μA

All specifications

Supply voltage	220–240 V
Protection class (IP)	IP40
Stray light monitoring	5 sec
Weight incl. wiring base	190 kg
Fuel	gas, dual fuel
Installation position	any
Weight including base	190 g
Air proving switch	1 working contact 4 A, 230 V
Mounting position	any

Part numbers

SKU	0452003
Additional article	852.124.208
