Honeywell Control box DMG970-N mod.03 0450003U

The Honeywell DMG970-N mod.03 0450003U is a control box for two-stage forced draught gas or oil burners. It operates at a supply voltage of 220–240 V and includes a stray light monitoring feature with a 5-second response. The device has a protection class of IP 40 and can be mounted in any position. It weighs 0.19 kg net, with a total weight of 190 kg including the wiring base. The control box is equipped with an air proving switch rated at 1 working contact, 4 A, 230 V.

When selecting a control box of this type, ensure the operating voltage matches the burner's supply (e.g., 220–240 V). Verify the air proving switch rating (e.g., 4 A at 230 V) and the required stray light monitoring time. The mounting position is flexible, but the protection class (e.g., IP 40) must suit the installation environment. Always compare the wiring base compatibility and the net weight to the existing unit before ordering.

Typical failures of such control boxes include malfunction due to stray light interference, which may cause the burner to shut down or fail to start. If the air proving switch fails, the burner may not receive the correct air flow signal, leading to lockout. Check the wiring connections and the condition of the flame detector, as a weak ionisation current can trigger safety shutdowns. Also, verify that the ambient conditions (e.g., humidity) do not exceed the specified limits, as this can cause erratic behaviour.
