Honeywell Control box MMI810.1 mod.33 0620220
SKU 0620220
Model MMI810.1 mod.33
Brand Honeywell
Photos
Key specifications
| Supply voltage | 220–240 V |
|---|---|
| Safety time | 3 s |
| Flame detector type | max. 20 |
| Protection class (IP) | IP44 |
| Body material | plastic |
| Fuel | gas, oil/gas |
| Firing stages | 2-stage |
| Safety standard | EN 298 |
| Air supply | forced draught |
| Installation position | any |
| Operating voltage | 220/240 V (-15...+10%) |
| Mounting position | any |
| Installation orientation | any |
| Weight including base | 350 g |
| Plug-in design | plug-in type |
| Display | programme display in colour |
| EN 298 classification | btllxn |
| Reset button type | illuminated pushbutton |
| Voltage tolerance | -15...+10% |
| Infrared detector model | ird 1020 |
| Program cam positions | 12 |
| Frequency | 50 Hz |
| Frequency range | 50–60 Hz |
| Flame detection methods supported | ionization probe, infrared flicker detector |
| Waiting time | 9 s |
| Air proving switch | 6 |
| Time delay term.6 / term.C | 10 s |
| Power consumption | 10 W |
| Amplifier sensitivity | 1 µA |
| Min. current from UV tube or ionisation probe | 5 µA |
| Weight incl. wiring base | 350 kg |
| Pre-purge time | 24 s |
| Pre-ignition time | 6 s |
428.05 EUR
389.14EUR
in stock · 5
incl. 21% VAT · 321.60 EUR excl. VAT · shipping calculated at checkout
- Worldwide shipping from stock
- Original manufacturer part
- Dispatch within 24 h for stocked items
Description
This Honeywell control box (SKU 0620220) is a plug-in type automatic burner control for gas and oil/gas forced draught burners. It operates at 220–240 V, 50 Hz, and consumes 10 W. The unit provides a 3 s safety time, 24 s pre-purge time, and 6 s pre-ignition time. It supports ionization probe and infrared flicker detector flame detection, and has a waiting time of 9 s. The control box has a plastic body, IP44 protection, and is classified to EN 298 as btllxn.
Further details
| Air pressure monitor | working contact 4 A, 230 V |
|---|---|
| Classified acc. to EN 298 | BTLLXN |
| Drive Mechanism | synchronous motor with speed reducer gears as the drive for the switching cam |
| Fuse rating | max. 10 A rapid, 6 A slow |
| Infrared flare detector | IRD 1020 |
| Insulation standard | IP 44 |
| Mounting attitude | any |
| Permissable ambient temp. | -20° C... +60°C |
All specifications
| Supply voltage | 220–240 V |
|---|---|
| Safety time | 3 s |
| Flame detector type | max. 20 |
| Protection class (IP) | IP44 |
| Body material | plastic |
| Fuel | gas, oil/gas |
| Firing stages | 2-stage |
| Safety standard | EN 298 |
| Air supply | forced draught |
| Installation position | any |
| Operating voltage | 220/240 V (-15...+10%) |
| Mounting position | any |
| Installation orientation | any |
| Weight including base | 350 g |
| Plug-in design | plug-in type |
| Display | programme display in colour |
| EN 298 classification | btllxn |
| Reset button type | illuminated pushbutton |
| Voltage tolerance | -15...+10% |
| Infrared detector model | ird 1020 |
| Program cam positions | 12 |
| Frequency | 50 Hz |
| Frequency range | 50–60 Hz |
| Flame detection methods supported | ionization probe, infrared flicker detector |
| Waiting time | 9 s |
| Air proving switch | 6 |
| Time delay term.6 / term.C | 10 s |
| Power consumption | 10 W |
| Amplifier sensitivity | 1 µA |
| Min. current from UV tube or ionisation probe | 5 µA |
| Weight incl. wiring base | 350 kg |
| Pre-purge time | 24 s |
| Pre-ignition time | 6 s |
Part numbers
| SKU | 0620220 |
|---|---|
| Additional article | 852.124.072 |
| Model | MMI810.1 mod.33 |
