Honeywell Burner control unit S4564C1000U

SKU S4564C1000U Model S4564C1000 Brand Honeywell

Photos

Key specifications

Supply voltage	230–240 V
Fan voltage	220–240 V
Fan current	1 A
Application	DBI or IP
Connector type	Molex 3003 multi-position connector
Ignition type	Direct ignition
Compatible gas valves	VR4600 series
Gas regulator compatibility	VR4605.. and VR4601.. series
Service life under maximum load	250000
Safety valve operator cycles	500000 cycles
Blocking operations	6000 cycles
Sparking hours	1000 hours
Model variant	Suffix C
Auxiliary fan	Yes
Electromagnetic filter	Y
Power consumption	5 W
Supported ignition systems	DBI and IP
Restart behavior	Repeats start sequence
Connector on top	Yes
Frequency range	50–60 Hz
Fault and operational status indication	(H)D, (A)larm, (F)lame HF

all specifications (21) ↓

347.79 EUR

316.17EUR

in stock · 1

incl. 21% VAT · 261.30 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This burner control unit is designed for gas appliances with DBI or IP ignition systems. It has a supply voltage of 230–240 V AC at 50–60 Hz and a power consumption of 5 W. The unit provides a fan output at 220–240 V AC with a maximum current of 1 A. It is compatible with Honeywell VR4600 series gas valves and can be directly connected to VR4605.. and VR4601.. regulators. A Molex 3003 multi-position connector is used for electrical connections, and fault status is indicated by (H)D, (A)larm, and (F)lame HF signals. Durability ratings include 250,000 cycles under maximum load, 500,000 safety valve operator cycles, 6,000 blocking operations, and 1,000 hours of sparking.

Further details

NTC sensor control	Gas valve is switched off when NTC sensor resistance falls below threshold
NTC sensor control resume	Restart when sensor resistance exceeds threshold after response time tTBB

Fits equipment

Honeywell VR4605..Honeywell VR4601..Honeywell VR4600..

All specifications

Supply voltage	230–240 V
Fan voltage	220–240 V
Fan current	1 A
Application	DBI or IP
Connector type	Molex 3003 multi-position connector
Ignition type	Direct ignition
Compatible gas valves	VR4600 series
Gas regulator compatibility	VR4605.. and VR4601.. series
Service life under maximum load	250000
Safety valve operator cycles	500000 cycles
Blocking operations	6000 cycles
Sparking hours	1000 hours
Model variant	Suffix C
Auxiliary fan	Yes
Electromagnetic filter	Y
Power consumption	5 W
Supported ignition systems	DBI and IP
Restart behavior	Repeats start sequence
Connector on top	Yes
Frequency range	50–60 Hz
Fault and operational status indication	(H)D, (A)larm, (F)lame HF

Part numbers

SKU	S4564C1000U
Additional article	534.412.150
Model	S4564C1000
