Honeywell Control box TF834.3 02234GR
SKU 02234GR
Model TF834.3
Brand Honeywell
Photos
Key specifications
| Supply voltage | 220–240 V |
|---|---|
| Safety time | 10 s |
| Protection class (IP) | IP44 |
| Post-ignition time | 20 sec |
| Weight incl. wiring base | 0.25 kg |
| Voltage tolerance | -15..+10% |
| Frequency | 50 Hz |
| Frequency range | 40–60 Hz |
| Power consumption | 5 W |
| Mounting position | any |
| Fuel | oil |
| Firing stages | 1- or 2-stage |
| Cycle type | intermittent |
| Burner capacity | up to 30 kg/h |
| Reset time from lockout | 60 sec |
| Pre-purge time | 12 s |
| Pre-ignition time | 12 s |
118.20 EUR
107.45EUR
in stock · 45
incl. 21% VAT · 88.80 EUR excl. VAT · shipping calculated at checkout
- Worldwide shipping from stock
- Original manufacturer part
- Dispatch within 24 h for stocked items
Description
Honeywell Control box TF834.3 02234GR is a control box for oil burners with one- or two-stage operation, suitable for burner capacity up to 30 kg/h. It operates on 220–240 V, 50 Hz, with a frequency range of 40–60 Hz and voltage tolerance of -15..+10%. Power consumption is 5 W. Safety time is 10 s, pre-purge time is 12 s, pre-ignition time is 12 s, post-ignition time is 20 s, and reset time from lockout is 60 s. It has protection class IP44, can be mounted in any position, and weighs 0.25 kg including wiring base.
Further details
| Compatible flame detectors | MZ 770 S, IRD 1010, UVD 970 |
|---|---|
| Flame Detector | photoresistor, infrared-flicker detector, UV solid state sensor |
| Mounting position | any |
| Power consumption | ca. 5 VA |
| Pre-ignition time | ca. 12 sec |
| Pre-purge time | ca. 12 sec |
| Protection class | IP44 |
All specifications
| Supply voltage | 220–240 V |
|---|---|
| Safety time | 10 s |
| Protection class (IP) | IP44 |
| Post-ignition time | 20 sec |
| Weight incl. wiring base | 0.25 kg |
| Voltage tolerance | -15..+10% |
| Frequency | 50 Hz |
| Frequency range | 40–60 Hz |
| Power consumption | 5 W |
| Mounting position | any |
| Fuel | oil |
| Firing stages | 1- or 2-stage |
| Cycle type | intermittent |
| Burner capacity | up to 30 kg/h |
| Reset time from lockout | 60 sec |
| Pre-purge time | 12 s |
| Pre-ignition time | 12 s |
Part numbers
| SKU | 02234GR |
|---|---|
| Additional article | 534.412.913 |
| Model | TF834.3 |
