Honeywell Gas control unit DKG972-N mod. 28 0432028
SKU 0432028
Model DKG972-N mod. 28
Brand Honeywell
Photos
Key specifications
| Supply voltage | 230 V |
|---|---|
| Protection class (IP) | IP40 |
| Operating voltage | 230.0 V |
| Consumption | 12 m3/h |
| Min. required ionization current (flame level) | 1 mkA |
| Sensitivity, operating mode (no flame level) | 0.7 µA |
| Sensitivity to ambient light | 0.4 µA |
| Max. Ionization current | 26 µA |
| Weight | 175 g |
| Serial fuse | 10 A fast, 6 A slow |
| Certification | EN 298:2003 |
| EN 298 classification | atllxn |
| Ice formation, water exposure and condensation | not allowed |
234.17 EUR
212.88EUR
in stock · 18
incl. 21% VAT · 175.93 EUR excl. VAT · shipping calculated at checkout
- Worldwide shipping from stock
- Original manufacturer part
- Dispatch within 24 h for stocked items
Description
This control box supervises and controls two-stage atmospheric gas burners. It is powered by a 230 V AC supply. Flame presence is detected by ionization current: the required minimum is 1 µA, the no-flame sensitivity level is 0.7 µA, sensitivity to ambient light is 0.4 µA, and the maximum measurable ionization current is 26 µA. The device is protected to IP40 and weighs 175 g. It is certified to EN 298:2003, with EN 298 classification atllxn. Water exposure, condensation, or ice formation must be avoided.
Further details
| Classification EN298 | ATLLXN |
|---|---|
| Ice formation, water exposure and condensation | not allowed |
| Parasitic capacity | Probe – Ground less than 1000 pF |
| Probe isolation | Probe – Ground more than 50 M |
| Protection class | IP 40 |
| Serial fuse | 10 A fast, 6 A slow |
| Tested in accordance with the European standard | EN 298:2003, as well as all related regulations and directives |
All specifications
| Supply voltage | 230 V |
|---|---|
| Protection class (IP) | IP40 |
| Operating voltage | 230.0 V |
| Consumption | 12 m3/h |
| Min. required ionization current (flame level) | 1 mkA |
| Sensitivity, operating mode (no flame level) | 0.7 µA |
| Sensitivity to ambient light | 0.4 µA |
| Max. Ionization current | 26 µA |
| Weight | 175 g |
| Serial fuse | 10 A fast, 6 A slow |
| Certification | EN 298:2003 |
| EN 298 classification | atllxn |
| Ice formation, water exposure and condensation | not allowed |
Part numbers
| SKU | 0432028 |
|---|---|
| Additional article | 852.124.132 |
| Model | DKG972-N mod. 28 |
