Kromschroder Burner control unit BCU460W3P2C0D1000K1E0-/LM400WF3O0E0- 88683322

SKU 88683322 Model BCU460W3P2C0D1000K1E0-/LM400WF3O0E0- Brand Kromschroder

Photos

Key specifications

Supply voltage	230 V
Flame detector type	ionization or UV
Cycle type	intermittent or continuous
Fuel	gas
Duty cycle	100
Safety integrity level	SIL 3 / PL e
Type approvals	EC-type, FM, EAC
Flame detection methods supported	ionization or UV
Safety feature	Manual reset lockout
Ignition transformer voltage	8 kV
Actuator type	LM400WF3O0E0

all specifications (11) ↓

3477.90 EUR

3161.73EUR

in stock · 1

incl. 21% VAT · 2613.00 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This burner control unit is a gas-fired control box from Kromschroder. It operates on 230 V and supports a 100% duty cycle. Flame monitoring is performed by ionization or UV detection methods. It is designed for intermittent or continuous cycling and includes a manual reset lockout safety feature. The integrated actuator type is LM400WF3O0E0, and the unit carries an 8 kV ignition transformer. It meets SIL 3 / PL e safety integrity and holds EC-type, FM, and EAC approvals.

Further details

All-in-one design	ignition unit, transformer, flame monitoring system, and air damper control module in one housing
Built-in display	shows current program status, device parameters, and flame signal level
Certifications	EC-type, FM, EAC, SIL 3 / PL E
Modular construction	includes ignition unit, transformer, flame monitoring system, and air damper control module in one housing

Choosing and fitting

Parts of this type are selected by matching the exact series and type designation, supply voltage, safety and pre-purge times, flame detection method, and the physical base or plug pattern. The control also drives modulation when paired with an actuator or variable-speed fan, so actuator compatibility must be confirmed. A direct substitution should only be made if the original part number is verified against the burner's specification.

Signs of failure

If the flame is not proved within the programmed safety time, the control locks out and must be manually reset. The equipment will fail to start and require a reset. This is a safety function, not necessarily a failure of the control itself.

All specifications

Supply voltage	230 V
Flame detector type	ionization or UV
Cycle type	intermittent or continuous
Fuel	gas
Duty cycle	100
Safety integrity level	SIL 3 / PL e
Type approvals	EC-type, FM, EAC
Flame detection methods supported	ionization or UV
Safety feature	Manual reset lockout
Ignition transformer voltage	8 kV
Actuator type	LM400WF3O0E0

Part numbers

SKU	88683322
Additional article	624.103.178
Model	BCU460W3P2C0D1000K1E0-/LM400WF3O0E0-
