What does the shop sell?

Spare parts for gas and oil burners and boilers: gas valves, nozzles, ignition electrodes and transformers, pressure switches, flame detectors, fuel pumps, servomotors and burner control boxes.

How large is the catalogue?

Over 100,000 part numbers from every major manufacturer, brought into one structure so that parts from different brands can be compared and replaced.

Can I find a part by its number?

Yes. The order number, the manufacturer model and any supplier code all lead to the same part, so a number from an old invoice or a nameplate is enough.

What if the part is discontinued?

The catalogue records what the manufacturer replaced it with, and which parts from other brands do the same job — together with the conditions that apply.

The company is based in London and ships across the United Kingdom, Europe and the rest of the world.

Is the shop open yet?

The catalogue is being assembled now. The shop opens as soon as it is ready.

Kromschroder Burner control unit IFD244-10/1WI 84621066

SKU 84621066 Model IFD244-10/1WI Brand Kromschroder

Photos

Key specifications

Supply voltage	230 V
Safety time	1 s
Flame detector type	ionization
Frequency	50–60 Hz
Flame detection methods supported	ionization
Ignition type	direct
Fuel	gas
Cycle type	intermittent
Certification	CE-63AP001/03
Safety standard	EN 298
EN 298 compliance	yes
Electronic ignition	integrated
Restart behavior	restart on flame failure
Quality assurance system	DIN EN ISO 9001

all specifications (14) ↓

1343.74 EUR

1221.58EUR

in stock · 1

incl. 21% VAT · 1009.57 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

The Kromschroder IFD244-10/1WI is a burner control unit for gas burners. It operates on 230 V at 50–60 Hz. The safety time is 1 second. It uses ionization flame detection and supports restart on flame failure. Direct ignition is provided with integrated electronic ignition. The unit is certified to CE-63AP001/03, complies with EN 298, and is manufactured under a quality system per DIN EN ISO 9001.

Further details

Mains voltage	230 V AC, 50/60 Hz

All specifications

Supply voltage	230 V
Safety time	1 s
Flame detector type	ionization
Frequency	50–60 Hz
Flame detection methods supported	ionization
Ignition type	direct
Fuel	gas
Cycle type	intermittent
Certification	CE-63AP001/03
Safety standard	EN 298
EN 298 compliance	yes
Electronic ignition	integrated
Restart behavior	restart on flame failure
Quality assurance system	DIN EN ISO 9001

Part numbers

SKU	84621066
Additional article	624.103.065
Model	IFD244-10/1WI
