Kromschroder Burner control unit IFD258-10/1Q 84621450
SKU 84621450
Model IFD258-10/1Q
Brand Kromschroder
Photos
Key specifications
| Supply voltage | 120 V |
|---|---|
| Safety time | 1 s |
| Flame detector type | Ionization or UV sensor |
| Protection class (IP) | IP54 |
| Ambient temperature | -20–60 °C |
| Weight | 610 g |
| Power consumption | 9 W |
| Flame control mode | Ionization or UV control |
| Flame detection methods supported | Ionization or UV |
| Sensor voltage | 230 |
| Relative humidity | No condensation permitted |
| Cable gland | M16 |
| Overvoltage category | III |
| Installation position | Any |
| Max. number of operating cycles | 250000 |
| Ignition type | Direct ignition |
| Operation type | Continuous operation |
| Burner capacity | Unlimited |
| Air supply | Atmospheric or forced draught |
| Frequency | 50–60 Hz |
| Multi-burner control | Yes |
| Grounding system | Grounded or ungrounded |
| Frequent cycling suitability | Yes |
| EN 298 compliance | Yes |
| Enclosure standard | IEC 529 |
| Net weight | 0.61 kg |
1220.15 EUR
1109.23EUR
in stock · 1
incl. 21% VAT · 916.72 EUR excl. VAT · shipping calculated at checkout
- Worldwide shipping from stock
- Original manufacturer part
- Dispatch within 24 h for stocked items
Description
This automatic burner control unit is designed to ignite and monitor industrial gas burners without capacity restrictions. It is a direct ignition unit suitable for continuous operation, and it can be used on atmospheric or forced draught burner systems. The unit operates with an ionization or UV flame sensor and has a safety time of 1 s. It accepts a supply voltage of 120 V at 50–60 Hz and consumes 9 W. The enclosure is rated IP54 per IEC 529, with an allowable ambient temperature range of -20 to 60 °C. It supports frequent cycling and multi-burner control.
Further details
| Cable gland | M16 |
|---|---|
| Display | Program status and flame signal intensity |
| Enclosure | IP 54 pursuant to IEC 529 |
| Flame Failure Behavior | Immediate fault lock-out or restart, switchable |
| Installation position | any |
| Mains voltage | 120 V AC, 50/60 Hz |
| Power consumption | approx. 9 VA |
| Relative humidity | no condensation permitted |
| Sensor current | > 2 µA |
| Sensor voltage | approx. 230 V AC |
All specifications
| Supply voltage | 120 V |
|---|---|
| Safety time | 1 s |
| Flame detector type | Ionization or UV sensor |
| Protection class (IP) | IP54 |
| Ambient temperature | -20–60 °C |
| Weight | 610 g |
| Power consumption | 9 W |
| Flame control mode | Ionization or UV control |
| Flame detection methods supported | Ionization or UV |
| Sensor voltage | 230 |
| Relative humidity | No condensation permitted |
| Cable gland | M16 |
| Overvoltage category | III |
| Installation position | Any |
| Max. number of operating cycles | 250000 |
| Ignition type | Direct ignition |
| Operation type | Continuous operation |
| Burner capacity | Unlimited |
| Air supply | Atmospheric or forced draught |
| Frequency | 50–60 Hz |
| Multi-burner control | Yes |
| Grounding system | Grounded or ungrounded |
| Frequent cycling suitability | Yes |
| EN 298 compliance | Yes |
| Enclosure standard | IEC 529 |
| Net weight | 0.61 kg |
Part numbers
| SKU | 84621450 |
|---|---|
| Additional article | 624.103.009 |
| Model | IFD258-10/1Q |
