Kromschroder Burner control unit IFD258-5/2W 84621640
SKU 84621640
Model IFD258-5/2W
Brand Kromschroder
Photos
Key specifications
| Supply voltage | 230 V |
|---|---|
| Safety time | 2 s |
| Flame detector type | ionization, UV |
| Protection class (IP) | IP54 |
| Ambient temperature | -20–60 °C |
| Weight | 682 g |
| Fuel | gas |
| Air supply | atmospheric or forced draught |
| Installation position | any |
| Ignition type | direct |
| Flame control mode | ionization or UV control |
| Burner capacity | unlimited capacity |
| Operation type | continuous operation |
| Cable gland | M16 |
| Sensor voltage | 230 |
| Overvoltage category | III pursuant to EN 60730 |
| Relative humidity | no condensation permitted |
| Reset button operating cycles | 1000 cycles |
| Mains button operating cycles | 1000 cycles |
| Frequency range | 50–60 Hz |
| Power consumption | 9 W |
| Max. number of operating cycles | 250000 |
| Safety standard | EN 60730 |
| EN 298 compliance | pursuant to EN 746-2 |
| Multi-burner control | yes |
| Grounded and ungrounded operation | yes |
| Frequent cycling suitability | yes |
| Net weight | 0.682 kg |
1220.15 EUR
1109.23EUR
in stock · 2
incl. 21% VAT · 916.72 EUR excl. VAT · shipping calculated at checkout
- Worldwide shipping from stock
- Original manufacturer part
- Dispatch within 24 h for stocked items
Description
This Kromschroder burner control unit, model IFD258-5/2W, is designed for industrial gas burners. It operates with a supply voltage of 230 V and consumes 9 W. The unit has a safety time of 2 seconds and supports flame detection via ionization or UV sensors. It has an IP54 protection class, can be installed in any position, and operates within an ambient temperature range of -20 to 60 °C. The unit is suitable for continuous operation and unlimited burner capacity, with a net weight of 682 g.
Further details
| Cable gland | M16 |
|---|---|
| Display | program status and flame signal intensity |
| Enclosure | IP 54 pursuant to IEC 529 |
| Flame Failure Behavior | immediate fault lock-out or restart, switchable |
| Installation position | any |
| Mains voltage | 230 V AC, 50/60 Hz |
| Power consumption | approx. 9 VA |
| Relative humidity | no condensation permitted |
| Sensor current | > 2 µA |
| Sensor voltage | approx. 230 V AC |
All specifications
| Supply voltage | 230 V |
|---|---|
| Safety time | 2 s |
| Flame detector type | ionization, UV |
| Protection class (IP) | IP54 |
| Ambient temperature | -20–60 °C |
| Weight | 682 g |
| Fuel | gas |
| Air supply | atmospheric or forced draught |
| Installation position | any |
| Ignition type | direct |
| Flame control mode | ionization or UV control |
| Burner capacity | unlimited capacity |
| Operation type | continuous operation |
| Cable gland | M16 |
| Sensor voltage | 230 |
| Overvoltage category | III pursuant to EN 60730 |
| Relative humidity | no condensation permitted |
| Reset button operating cycles | 1000 cycles |
| Mains button operating cycles | 1000 cycles |
| Frequency range | 50–60 Hz |
| Power consumption | 9 W |
| Max. number of operating cycles | 250000 |
| Safety standard | EN 60730 |
| EN 298 compliance | pursuant to EN 746-2 |
| Multi-burner control | yes |
| Grounded and ungrounded operation | yes |
| Frequent cycling suitability | yes |
| Net weight | 0.682 kg |
Part numbers
| SKU | 84621640 |
|---|---|
| Additional article | 624.103.062 |
| Model | IFD258-5/2W |
