Kromschroder Burner control unit IFS110IM-W-5/1/1T 84367430

SKU 84367430 Model IFS110IM-W-5/1/1T Brand Kromschroder

Photos

Key specifications

Supply voltage	220–240 V
Flame detector type	Ionization or UV
Ambient temperature	-20–60 °C
Frequency	50–60 Hz
Power consumption	5 W
Max output current per output	1 A
Max total current for valves and ignition transformer	2 A
Ionisation electrode	220 V
Cable gland	PG 9
Installation position	any
Weight	750 g
Remote reset signal	yes
False flame check	yes
Ignition and flame extinguishing	combined
Fuel	gas
External alarm signal	yes
Semiconductor automation	yes
High switching frequency	yes

all specifications (18) ↓

2871.85 EUR

2610.77EUR

in stock · 1

incl. 21% VAT · 2157.66 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This gas burner control unit from Kromschroder serves for automatic ignition and flame monitoring of gas burners. It operates on 220–240 V AC, 50–60 Hz, with a power consumption of 5 W. Flame detection is performed by an ionization electrode or a UV sensor, and the unit supports combined ignition and flame-extinguishing operation. It performs a false-flame check before start-up and after shutdown, provides a remote reset signal and an external alarm output. The semiconductor automation enables high switching frequency. Technical specifications include an ambient temperature range of -20 to 60 °C, a weight of 750 g, a PG 9 cable gland, and any installation position.

Further details

Cable gland	for Pg 9
Contact load	max. 1 A per output
Fault indicator	lamp in the reset button and connection for external fault indicator
Fitting positon	arbitrary
Ionisation current	> 1 µA
Operating voltages	220/240 V, 50/60 Hz
Protective grade	IP 40 acc. to DIN 40 050
Reaction time	< 1s
Remote reset	yes
Total load	max. 2 A

All specifications

Supply voltage	220–240 V
Flame detector type	Ionization or UV
Ambient temperature	-20–60 °C
Frequency	50–60 Hz
Power consumption	5 W
Max output current per output	1 A
Max total current for valves and ignition transformer	2 A
Ionisation electrode	220 V
Cable gland	PG 9
Installation position	any
Weight	750 g
Remote reset signal	yes
False flame check	yes
Ignition and flame extinguishing	combined
Fuel	gas
External alarm signal	yes
Semiconductor automation	yes
High switching frequency	yes

Part numbers

SKU	84367430
Additional article	624.103.078
Model	IFS110IM-W-5/1/1T
