Siemens Control box RWF50.20A9

The Siemens RWF50.20A9 is a control box for oil or gas burners, used for temperature and pressure control in heating plants. It manages the burner ignition and safety sequence, including pre-purge, flame monitoring, and fuel valve operation. The unit can be set to two-stage mode via an external switch for controlling two-stage burners. It uses an ionisation electrode or UV/IR detector for flame sensing. A built-in thermostatic function turns the burner on and off, and the control action can be reversed for cooling applications. It functions as a three-position compact step controller without output feedback.

Burner control boxes of this type are selected by matching the exact series and type designation to the burner specification. Supply voltage, safety time, pre-purge time, and flame detection method are critical parameters. Even within the same brand, different series are generally not interchangeable because a mismatched safety time creates a safety hazard. When replacing, confirm the part number and the configuration of the base or plug connector. The terminal layout and factory-set times are matched to the burner model, so always verify compatibility with the technical data sheet of the exact article before ordering.
