Siemens Electronic boards & displays AZL23.00A9
SKU AZL23.00A9
Brand Siemens
Photos
Key specifications
| Interface type | BCI interface |
|---|---|
| Weight | 2000 g |
| Ingress protection | IP54 |
| Packaging dimensions | 14,00 x 15,00 x 5,00 |
| Packaging quantity | 1 |
| Packaging unit of measure | CMT |
| Compatible control type | LMV2/LMV3/LME |
| Net weight | 0.156 kg |
233.30 EUR
212.09EUR
in stock · 1
incl. 21% VAT · 175.28 EUR excl. VAT · shipping calculated at checkout
- Worldwide shipping from stock
- Original manufacturer part
- Dispatch within 24 h for stocked items
Description
This is an operator panel with a display for Siemens burner controls. It connects to the burner control via a BCI interface. It supports the LMV2, LMV3 and LME control series. The panel has IP54 ingress protection. Its net weight is 0.156 kg. It provides readout of operating parameters, diagnostics and settings.
Further details
| Application | Burner control systems, boiler plants, industrial automation |
|---|---|
| Functions | Display, operation and parameterization of safety- and non-safety-related burner functions |
| Installation | Directly on the burner or in control panels installed close to the burner |
| Mounting | On burner or in control panel |
| Safety function | Non-safety function; failure does not disable burner |
Choosing and fitting
Displays of this type are selected by matching the burner control series and the communication interface (typically BCI). They are mounted on the control panel front or burner enclosure and do not replace the safety control. Before ordering, verify the display model matches the control unit designation; a mismatched display may fail to communicate or show incorrect data. Replacements should be installed only after de-energising the system.
Signs of failure
If a display of this type is mismatched, it may fail to communicate or show incorrect data. The display itself does not handle safety functions; its failure does not directly disable the burner, but it removes the operator's ability to read status and diagnose faults. Check that the display model matches the control unit's designation and that the communication link is intact.
Fits equipment
Siemens Burner control series (specific models not named)Siemens LMV2Siemens LMV3Siemens LMESiemens LME39
All specifications
| Interface type | BCI interface |
|---|---|
| Weight | 2000 g |
| Ingress protection | IP54 |
| Packaging dimensions | 14,00 x 15,00 x 5,00 |
| Packaging quantity | 1 |
| Packaging unit of measure | CMT |
| Compatible control type | LMV2/LMV3/LME |
| Net weight | 0.156 kg |
Part numbers
| SKU | AZL23.00A9 |
|---|---|
| Additional article | 884.253.001 |
