Honeywell Gas boiler control unit S4562DM1022V01U

SKU S4562DM1022V01U Brand Honeywell

Photos

Key specifications

Supply voltage	220–240 V
Actuator type	two-position electric actuator
Catalogue article numbers	534.568.715
Safety feature	integrated burner control protection functions

all specifications (4) ↓

202.84 EUR

184.40EUR

in stock · 1

incl. 21% VAT · 152.40 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This is a Honeywell gas boiler control unit (category: control board) with SKU S4562DM1022V01U. It operates at a supply voltage of 220–240 V and incorporates integrated burner control protection functions. This unit drives a two-position electric actuator and is designed for use with Honeywell VK41 series gas regulators.

Further details

Application	gas boilers, heaters and water heaters equipped with an automatic ignition system
Control features	configurable ignition process, flame control, gas flow adjustment for main and pilot burners
Ignition systems supported	spark ignition (DBI) and pilot burner (IP)
Installation feature	special connector at the top of the gas regulator
Mounting feature	can be installed at a 90° angle in different directions from vertical
System type	joint control and ignition system (CVI)

Choosing and fitting

Control units of this type are selected by verifying compatibility with the specific gas regulator series (e.g., VK41) and matching the supply voltage. The unit mounts onto the regulator's top connector. Its two-position electric actuator can be oriented in 90-degree steps around the vertical axis, allowing flexible placement. Confirm that the actuator type and electrical ratings match the system before installation.

Fits equipment

Honeywell VK41 Honeywell VK41 series gas regulators VK41 series

All specifications

Supply voltage	220–240 V
Actuator type	two-position electric actuator
Catalogue article numbers	534.568.715
Safety feature	integrated burner control protection functions

Part numbers

SKU	S4562DM1022V01U
Additional article	534.568.715
