Kromschroder Flame sensor UVS5G1 84333031

SKU 84333031 Model UVS5G1 Brand Kromschroder

Photos

Key specifications

Detection principle	UV
Distance between UV sensor and flame	300–400 mm
Ambient temperature	-40–80 °C
Weight	360 g
Fuel	gas
Application	monitoring flames in gas burners
material	aluminum
Service life	approx. 10,000 operating hours
Cable gland diameter	7–13 mm
Cable gland thread size	M20
Device type	UV flame sensor
Design features	integrated heat guard
Catalogue article numbers	84333031, 624.208.003

all specifications (13) ↓

717.60 EUR

652.36EUR

in stock · 2

incl. 21% VAT · 539.14 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This UV flame sensor from Kromschroder is designed to monitor flames in gas burners by detecting ultraviolet radiation. It is housed in an aluminum case with an integrated heat guard and an M20 cable gland for cables 7 to 13 mm in diameter. It can be operated in ambient temperatures from -40 to 80 °C and weighs 360 g. The recommended distance between the UV sensor and the flame is 300 to 400 mm. Its service life is approximately 10,000 operating hours. It is compatible with Elster Kromschroder automatic burner control units of types IFS, IFD, PFS, PFD, IFW, PFF, BCU, and PFU.

Further details

Cable gland	for cable diameters of 7 to 13 mm
Clamping range of the connection terminals	≤ 2.5 mm²
Enclosure	IP 65
Min. DC signal	1 μA
Service life of the UV tube	approx. 10,000 operating hours
UV tube	P578, spectral range: 190–270 nm, max. sensitivity: 210 nm ± 10 nm

Fits equipment

M20 cable glandElster Kromschroder IFSElster Kromschroder IFDElster Kromschroder PFSElster Kromschroder PFDElster Kromschroder IFWElster Kromschroder PFFElster Kromschroder BCUElster Kromschroder PFU

All specifications

Detection principle	UV
Distance between UV sensor and flame	300–400 mm
Ambient temperature	-40–80 °C
Weight	360 g
Fuel	gas
Application	monitoring flames in gas burners
material	aluminum
Service life	approx. 10,000 operating hours
Cable gland diameter	7–13 mm
Cable gland thread size	M20
Device type	UV flame sensor
Design features	integrated heat guard
Catalogue article numbers	84333031, 624.208.003

Part numbers

SKU	84333031
Additional article	624.208.003
Model	UVS5G1
