Kromschroder Gas filter GFK32R40-6 81938200

SKU 81938200 Model GFK32R40-6 Brand Kromschroder

Photos

Key specifications

Application	cleans gas and air
DN (Nominal diameter)	32 mm
Maximum pressure (Pu)	4 bar
Thread type	Rp internal thread
Replacement pressure drop	20 mbar

all specifications (5) ↓

—price on request

on order

shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This Kromschroder gas filter, model GFK32R40-6 (SKU 81938200), is designed to clean gas and air. It has a nominal diameter of 32 mm and features a Rp internal thread. The maximum operating pressure is 4 bar. The filter element should be replaced when the pressure drop across it reaches 20 mbar.

Further details

Function	Protection of valve, burner control, and metering components from particles, dirt, or pipe debris
Installation position	In the gas supply line upstream of the gas valve
Maintenance requirement	Filter element must be cleaned or replaced at intervals specified by the burner manufacturer
Pressure Test Points	pressure test point at the inlet and outlet

Choosing and fitting

Parts of this type are selected by connection size and thread type, required flow capacity for burner output, and filtration fineness. They are installed upstream of the gas valve, typically between the main shut-off valve and the gas valve train. When replacing, renew all gaskets and ensure the flow direction arrow on the housing matches the gas flow.

Signs of failure

Typical failure of this kind of component is clogging with particles or pipe debris. A clogged filter increases pressure drop, which may cause incomplete combustion or burner lockout. When these symptoms occur, check the filter element and clean or replace it as recommended by the burner manufacturer.

All specifications

Application	cleans gas and air
DN (Nominal diameter)	32 mm
Maximum pressure (Pu)	4 bar
Thread type	Rp internal thread
Replacement pressure drop	20 mbar

Part numbers

SKU	81938200
Additional article	624.880.030
Model	GFK32R40-6
