Honeywell Gas pressure regulator FR124-3/4AM-R FR124AM-3/4-R

SKU FR124AM-3/4-R Model FR124-3/4AM-R Brand Honeywell

Photos

Key specifications

Design features	built-in thermostat
Control type	thermostatic
Application	solid fuel boilers
Control features	lever with chain

all specifications (4) ↓

39.93 EUR

36.30EUR

in stock · 28

incl. 21% VAT · 30.00 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This gas pressure regulator from Honeywell is a thermostatic draught regulator intended for solid fuel boilers. Its built-in thermostat measures the boiler temperature and, via a lever with a chain, opens or closes the air damper to control combustion. It is compatible with solid fuel boilers from Burnit, Wirbel, Viadrus, Buderus, KCHM, Zota, Atmos, and Don.

Further details

Control mechanism	built-in thermostat measures temperature and controls air supply via lever with chain
Function	controls the combustion process by changing the air supply to the boiler
Installation orientation	vertical or near-vertical section of flue with flap horizontal
Key parameter	flue pipe diameter and range of draught adjustment
Operation principle	gravity-operated counterbalanced flap opens at set draught level
Purpose	controls the combustion process by changing the air supply

Choosing and fitting

Parts of this type are selected by flue pipe diameter and draught adjustment range. To ensure a proper seal, the regulator must match the flue pipe size. Install in a vertical or near-vertical flue section with the flap horizontal, and verify the flow direction marking. Before ordering, measure the flue diameter and check the existing regulator's orientation.

Signs of failure

When the hinge or flap seal becomes worn or sticky, the regulator may fail to maintain consistent draught, causing unstable combustion or overfiring. Check the hinge and seal for wear, sticking, or damage, and ensure the flap moves freely.

Fits equipment

burnit wirbel viadrus buderus kchm zota atmos don

All specifications

Design features	built-in thermostat
Control type	thermostatic
Application	solid fuel boilers
Control features	lever with chain

Part numbers

SKU	FR124AM-3/4-R
Additional article	534.662.900
Model	FR124-3/4AM-R
