Honeywell solenoid valve VK8115V1168B
SKU VK8115V1168B
Model VK8115V1168
Brand Honeywell
Photos
Key specifications
| Connection thread | 3/4" external |
|---|---|
| Actuator type | servo drive |
| connection_type | flanged |
| Inlet and outlet diameter | 18.6 mm |
| Electrical connection | connector or plug-in rectifier unit |
| Design features | positive feedback system |
| Input screen | on the input side |
| Max. inlet pressure | 60 mbar |
| Flow capacity | 2.9 m³/h |
| Coil voltage type | 24 V |
| Built-in valve | two main valves |
| Operating voltage | 24 V |
| Back pressure (1st valve) | 50 mbar |
| Maximum inlet pressure | 60 mbar |
| Maximum operating pressure | 60 mbar |
| Valve closing force variants | b+j, b+c, b+b |
| Mounting feature | holes on lower part |
| Pressure drop | 5 mbar |
| Pressure measuring points | top |
| Pressure test points | top |
| Leakage requirements | EN 126 |
| Pressure sensor pipe diameter | 0.5 inch |
| Operating position | upright |
| Nominal inlet gas pressure | 25 mbar |
| Ambient pressure | 1013 mbar |
| Diaphragm diameter | 2.8 mm |
| Built-in filter | fine-mesh filter |
| Optional output filter | additional output filter |
| Power options | 24 V |
| Ignition electronics compatibility | various ignition regulators, except s4565/s4585 |
| Ignition regulator exception | s4565/s4585 series regulators |
| Operating principle | positive feedback system |
| Pressure servo controller | pressure servo controller |
| Pressure relief valve | pressure relief valve |
| Output pressure stability | stable output pressure |
| Reliability | high reliability |
| Included components | gas valve and ignition regulator |
| Housing type | standard body |
| Control type | servo drive |
| Softlite technology | softlite technology |
| Regulation of the mixture of gas and air in a ratio of 1 | 1 |
| Control features | electronic two-level regulator |
| Two electrical devices | two electronic devices |
| Gas type | heating, natural and liquefied gas |
| Side socket | side output |
| Outlet Orientation | side |
143.75 EUR
130.68EUR
in stock · 2
incl. 21% VAT · 108.00 EUR excl. VAT · shipping calculated at checkout
- Worldwide shipping from stock
- Original manufacturer part
- Dispatch within 24 h for stocked items
Description
This Honeywell gas valve, model VK8115V1168, operates at 24 V and is driven by a servo actuator. It has a flow capacity of 2.9 m³/h with a pressure drop of 5 mbar, and a maximum inlet pressure of 60 mbar. The valve incorporates two main valves and uses a positive feedback system for pressure control. It includes a fine-mesh inlet filter and is compatible with natural and liquefied gas. The connection is flanged with a 3/4" external thread, and it is intended for upright installation.
Further details
| Adjustment method | smooth and flexible regulation with ability to adapt to different control methods |
|---|---|
| Electrical Connection | special connector or plug-in rectifier unit |
| Pressure measurement setup | sensor connected to 1/2-inch pipe, 10 times diameter, hose length 5 pipe diameters |
| Pressure measuring points | top for measuring inlet and outlet pressure |
| Safety Feature | automatic closing of the main valve in case of power outage or excess gas pressure |
| Smooth regulation with amplification | smooth and flexible regulation with the ability to adapt to different control methods |
Choosing and fitting
Gas valves of this type are selected by matching the connection thread (3/4" external), flanged connection, operating voltage (24 V), and flow capacity (2.9 m³/h at 5 mbar pressure drop). They are mounted upright using holes on the lower part. Electrical connection is via a connector or a plug-in rectifier unit; compatibility with the ignition regulator must be verified, excluding s4565/s4585 series regulators.
All specifications
| Connection thread | 3/4" external |
|---|---|
| Actuator type | servo drive |
| connection_type | flanged |
| Inlet and outlet diameter | 18.6 mm |
| Electrical connection | connector or plug-in rectifier unit |
| Design features | positive feedback system |
| Input screen | on the input side |
| Max. inlet pressure | 60 mbar |
| Flow capacity | 2.9 m³/h |
| Coil voltage type | 24 V |
| Built-in valve | two main valves |
| Operating voltage | 24 V |
| Back pressure (1st valve) | 50 mbar |
| Maximum inlet pressure | 60 mbar |
| Maximum operating pressure | 60 mbar |
| Valve closing force variants | b+j, b+c, b+b |
| Mounting feature | holes on lower part |
| Pressure drop | 5 mbar |
| Pressure measuring points | top |
| Pressure test points | top |
| Leakage requirements | EN 126 |
| Pressure sensor pipe diameter | 0.5 inch |
| Operating position | upright |
| Nominal inlet gas pressure | 25 mbar |
| Ambient pressure | 1013 mbar |
| Diaphragm diameter | 2.8 mm |
| Built-in filter | fine-mesh filter |
| Optional output filter | additional output filter |
| Power options | 24 V |
| Ignition electronics compatibility | various ignition regulators, except s4565/s4585 |
| Ignition regulator exception | s4565/s4585 series regulators |
| Operating principle | positive feedback system |
| Pressure servo controller | pressure servo controller |
| Pressure relief valve | pressure relief valve |
| Output pressure stability | stable output pressure |
| Reliability | high reliability |
| Included components | gas valve and ignition regulator |
| Housing type | standard body |
| Control type | servo drive |
| Softlite technology | softlite technology |
| Regulation of the mixture of gas and air in a ratio of 1 | 1 |
| Control features | electronic two-level regulator |
| Two electrical devices | two electronic devices |
| Gas type | heating, natural and liquefied gas |
| Side socket | side output |
| Outlet Orientation | side |
Part numbers
| SKU | VK8115V1168B |
|---|---|
| Additional article | 534.322.234 |
| Model | VK8115V1168 |
