Brahma Gas solenoid valve E6G*A P*1/2*AFD5 13707513

The Brahma E6G*A P*1/2*AFD5 gas solenoid valve (SKU 13707513) is a normally closed, quick-opening valve designed for use in gas burner and boiler systems. It operates on alternating current with a supply voltage of 230 V and a frequency of 50–60 Hz. The valve has a closing time of 1 second and an opening time of 1 second, and it is certified to EN161 with CE marking. Its body is made of brass, and it features a quick-release connection for DIN43650, with an ingress protection rating of IP65. The valve can be installed in both vertical and horizontal positions, and it includes a flow direction arrow and requires a hex key for installation.

When selecting a gas solenoid valve of this type, ensure that the supply voltage, frequency, and connection type match the system requirements. The valve must be installed with the flow direction arrow aligned with the gas flow, and the inlet pressure must not exceed the pressure indicated on the valve. Use a hex key of the appropriate size to avoid damaging the protective shell, and verify that no foreign objects have entered the valve before installation. The valve can be mounted vertically or horizontally, and the connection type (e.g., DIN43650) must be compatible with the existing wiring.

Common failure modes for gas solenoid valves include coil burnout, sticking due to debris, or diaphragm damage, which can result in the valve failing to open or close properly. Symptoms may include the burner not igniting, intermittent operation, or gas flow continuing when the valve should be closed. Check the coil resistance and ensure the valve is clean and free of obstructions, and verify that the inlet pressure is within the specified range.
