Brahma Gas solenoid valve E6G*L*3/8*GMO 13775001

This gas solenoid valve (model E6G*L*3/8*GMO) is a normally closed, slow-opening, silent unit. It operates from 230 V AC/DC supply at 50–60 Hz, consuming 20 W. The brass body has a 10 mm nozzle, 3/8-inch connection, and a flow capacity of 3.9 m³/h. Closing time is 1 s, and opening time is adjusted with a screw. The valve can be mounted vertically or horizontally, has IP54 protection, terminal block connection, and carries a flow direction arrow. It is Class A and suitable for domestic and industrial applications.

For gas solenoid valves of this kind, selection is based on supply voltage, connection thread, nozzle diameter, and required flow capacity. They can be installed vertically or horizontally; align the arrow on the body with the flow direction before tightening. When mounting, use a correctly sized hex key and ensure the inlet pressure does not exceed the value marked on the valve. Always compare the electrical characteristics (AC/DC, voltage, frequency) with the burner control before ordering.
