Brahma Gas valve E6GS103/8*GMO 13747002

SKU 13747002 Model E6G*S10*3/8*GMO Brand Brahma

Photos

Key specifications

Supply voltage	230 V
Valve classification	A
Closing time	1 s
Installation position	vertical and horizontal
Body material	brass
Nozzle diameter	10 mm
Weight	700 g
Electrical connection	terminal block connection
Ingress protection	IP54
Opening type	quick opening, silent
Application	domestic and industrial installations
Pressure sampling control point	+
Frequency	50–60 Hz
Power consumption	20 W
Flow capacity	3.9 m³/h

all specifications (15) ↓

136.57 EUR

124.15EUR

in stock · 2

incl. 21% VAT · 102.60 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This gas valve shuts off the gas flow in domestic and industrial installations. It operates on 230 V AC (50–60 Hz) and is rated valve class A. The brass body has a 10 mm nozzle, and the valve closes within 1 s. Flow capacity is 3.9 m³/h with a power consumption of 20 W. The electrical connection is via a terminal block, protection rating IP54, and the valve can be installed vertically or horizontally. It offers quick, silent opening.

Further details

Power supply type	alternating current; valve controlled by DC signal via built-in bridge rectifier

All specifications

Supply voltage	230 V
Valve classification	A
Closing time	1 s
Installation position	vertical and horizontal
Body material	brass
Nozzle diameter	10 mm
Weight	700 g
Electrical connection	terminal block connection
Ingress protection	IP54
Opening type	quick opening, silent
Application	domestic and industrial installations
Pressure sampling control point	+
Frequency	50–60 Hz
Power consumption	20 W
Flow capacity	3.9 m³/h

Part numbers

SKU	13747002
Additional article	246.322.065
Model	E6GS103/8*GMO

Brahma Gas valve E6G*S10*3/8*GMO 13747002
