Brahma Gas valve EG12*AP*AFD 7 13877701

Key specifications

Supply voltage	230 V
Nozzle diameter	15 mm
Weight	800 g
Closing time	1 s
Opening time	1 sec
Installation position	vertical and horizontal
Cable gland	pg9
Body material	die-cast aluminum
Power supply flexibility	alternating or direct current
Built-in filter	mesh filter at inlet
Valve classification	a
Gas group	2
Opening type	quick-opening valve
Silent operation	yes
Variable opening modes	yes
Application	civil and industrial use
Winding type	AC
Frequency	50–60 Hz
Power consumption	20 W
Flow capacity	7.5 m³/h

Supply voltage

230 V

Nozzle diameter

15 mm

Weight

800 g

Closing time

1 s

Opening time

1 sec

Installation position

vertical and horizontal

Cable gland

pg9

Body material

die-cast aluminum

Power supply flexibility

alternating or direct current

Built-in filter

mesh filter at inlet

Valve classification

Gas group

Opening type

quick-opening valve

Silent operation

yes

Variable opening modes

yes

Application

civil and industrial use

Winding type

Frequency

50–60 Hz

Power consumption

20 W

Flow capacity

7.5 m³/h

all specifications (20) ↓

Description

This is a Brahma gas valve, model EG12*AP*AFD 7 (SKU 13877701), intended for civil and industrial gas burner applications. It operates on 230 V at 50–60 Hz, consumes 20 W, and can work on alternating or direct current. The valve has a nominal flow capacity of 7.5 m³/h and a nozzle diameter of 15 mm. It is a quick-opening valve with an opening and closing time of 1 second. The body is die-cast aluminum, the unit weighs 800 g, and the cable gland is PG9. It has a mesh inlet filter, is classified in group 2, class A, and can be installed vertically or horizontally.

Contamination prevention	prevents dirt with thickness more than 1 mm
Electrical Connection	quick-start connection for DIN43650-IP65 plug (GFD IP40)
Flow Direction Marking	arrow on body indicates direction of fuel flow

Contamination prevention

prevents dirt with thickness more than 1 mm

Electrical Connection

quick-start connection for DIN43650-IP65 plug (GFD IP40)

Flow Direction Marking

arrow on body indicates direction of fuel flow

All specifications

Supply voltage	230 V
Nozzle diameter	15 mm
Weight	800 g
Closing time	1 s
Opening time	1 sec
Installation position	vertical and horizontal
Cable gland	pg9
Body material	die-cast aluminum
Power supply flexibility	alternating or direct current
Built-in filter	mesh filter at inlet
Valve classification	a
Gas group	2
Opening type	quick-opening valve
Silent operation	yes
Variable opening modes	yes
Application	civil and industrial use
Winding type	AC
Frequency	50–60 Hz
Power consumption	20 W
Flow capacity	7.5 m³/h
