Brahma Gas valve EG12*L*GFD 13923205

This gas solenoid valve from Brahma, model EG12*L*GFD, is intended for civil and industrial applications. It runs on 230 V AC supply at 50–60 Hz and draws 20 W. The valve has a flow capacity of 7.5 m³/h, a nozzle diameter of 15 mm, and a closing time of 1 second. A mesh filter at the inlet with 1 mm cell size prevents particles from entering. The body is made of die-cast aluminum, and the net weight is 0.9 kg. It complies with CE and EN161 standards.

Gas solenoid valves of this kind are selected by matching the supply voltage, gas group, and connection size to the existing installation. Check the flow capacity requirement and confirm that the valve's nozzle diameter and pressure rating suit the application. During installation, position the valve so the arrow on the housing points in the direction of fuel flow. Use a hex key on the valve body to avoid twisting the shell when tightening. Ensure the inlet pressure never exceeds the value indicated on the label and that no foreign objects enter the valve.
