Brahma Gas valve EG30*SR.5*GFD 13943500

This gas valve is suitable for civil and industrial use. Its nominal diameter and hole diameter are both 30 mm, and it weighs 2.8 kg. The valve requires a 230 V, 50-60 Hz supply and a 35 V control voltage. The die-cast aluminum body has IP54 protection and is fitted with a PG9 cable gland. It opens and closes in 1 second and can be mounted vertically or horizontally; the body bears a flow direction arrow.

When selecting a replacement gas valve, verify that the nominal diameter, supply voltage, frequency, and gas group match the original. Such valves may be installed vertically or horizontally. During installation, ensure the arrow on the valve body indicates the direction of fuel flow. Avoid twisting the shell when mounting, prevent foreign objects from entering the body, and confirm that the maximum fuel inlet pressure does not exceed the value on the valve label.
