Brahma Gas valve EG40*L*GMO 13950200

This normally closed gas valve, model EG40*L*GMO by Brahma, is a class A safety shut-off device per EN 161. It is intended for residential and industrial gas installations with inlet pressure up to 200 mbar. The valve body is pressure-cast aluminum, with IP54 ingress protection and an integral metal wire mesh filter (1 mm cells) at the inlet. Energizing the coil through a special rectifier provides a high starting power that reduces after start-up to prevent overheating. Connections are G 1 1/2" female threads, and the net weight is 3.7 kg. It can be mounted vertically or horizontally following the flow direction marked on the housing.

When choosing a replacement valve of this type, verify the connection thread size and pitch, the maximum operating pressure, and the electrical characteristics of the coil against the equipment control board. Confirm that the valve is fall-safe and matches the safety class required by the installation. Check whether the original valve is fitted with an integrated or external filter and whether a relief valve is required. For fitting, the unit must be positioned so the arrow on the housing matches the gas flow direction; both vertical and horizontal orientations are acceptable if the manufacturer's spec allows.
