Honeywell Gas solenoid valve VK8115V1036U
SKU VK8115V1036U
Model VK8115V1036
Brand Honeywell
Photos
Key specifications
| Max. inlet pressure | 60 mbar |
|---|---|
| Connection thread | Flanged connection |
| Supply voltage | 24 V |
| Coil voltage type | AC |
| Actuator type | Solenoid |
| Control features | electronic two-level regulator |
| Gas type | natural and liquefied gas |
| Operating voltage | 24 V |
| Housing type | standard housing |
| Diaphragm diameter | 2.8 mm |
| Pilot gas connection diameter | 4 mm |
| Inlet and outlet diameter | 18.6 mm |
| Ambient temperature | 0–70 °C |
| Softlite technology | Smooth and safe ignition |
| Design features | Positive feedback system |
| Two electrical devices | Two electrical devices |
| Pressure drop | 5 mbar |
| Valve type | pressure relief valve |
| Built-in valve | two valves (1st and 2nd) |
| Included components | VK8115V1036 valve and ignition regulator |
| Leakage requirements | EN126 |
| Nominal inlet gas pressure | 25 mbar |
| Pressure sensor pipe diameter | 0.5 inch |
| Operating position | upright |
| Maximum inlet pressure | 60 mbar |
| Maximum operating pressure | 60 mbar |
| Catalogue article numbers | 534.331.090 |
| Regulation of the mixture of gas and air in a ratio of 1 | 1 |
| Ambient pressure | 1013 mbar |
| Built-in filter | yes |
| Optional output filter | yes |
| Ignition electronics compatibility | various ignition regulators except S4565/S4585 |
| Throttle valve regulation | yes |
| Input screen | on the input side |
| Pressure relief valve | yes |
| Filter cleaning | not intended for cleaning |
| Side socket | yes |
| Output pressure stability | stable output pressure |
| Reliability | reliable in operation |
| Pressure servo controller | high-tech pressure servo controller |
| Ignition regulator exception | S4565/S4585 series regulators |
| Flanged connections | flanged connections |
| Control type | pressure control using a servo |
| connection_type | flanged |
| Back pressure (1st valve) | 10 mbar |
| Frequency | 50 Hz |
| Flow capacity | 3.2 m³/h |
143.75 EUR
130.68EUR
in stock · 6
incl. 21% VAT · 108.00 EUR excl. VAT · shipping calculated at checkout
- Worldwide shipping from stock
- Original manufacturer part
- Dispatch within 24 h for stocked items
Description
Gas solenoid valve with flanged connections for burner control systems. It operates on 24 V AC at 50 Hz and is suitable for natural and liquefied gas. Maximum inlet pressure is 60 mbar; nominal inlet pressure is 25 mbar. Flow capacity is 3.2 m³/h at a pressure drop of 5 mbar. The unit contains two valves (1st and 2nd) plus an ignition regulator, and features a positive feedback system and a pressure relief valve. It includes an electronic two-level regulator, Softlite ignition technology, a built-in filter, and a side socket; inlet/outlet diameter is 18.6 mm and pilot gas connection is 4 mm.
Further details
| Application | burner control system, ignition, flame control, gas flow control for pilot and main burner |
|---|---|
| Control Type | Precision pressure control using a servo |
| Measurement setup | sensor connected to 1/2-inch pipe, 10 diameters long, short hose 5 pipe diameters |
| Mounting Feature | holes at the bottom for mounting |
| Operating Principle | gas passes through the servo controller and opens the main valve; system maintains constant pressure |
| Optional Output Filter | Additional output filter can be installed |
| Outlet Orientation | side gas outlet for the main and pilot burners |
| Pressure Measuring Fittings | silicone tubes 4 or 6 mm |
| Pressure Measuring Points | top for measuring inlet and outlet pressure |
| Pressure control components | Pressure servo controller and pressure relief valve |
| Regulation amplification | Flexible and smooth regulation with amplification |
| Safety Feature | automatic closing of the main valve in case of lack of power supply or excess gas pressure |
| Smooth Regulation With Amplification | smooth regulation with amplification for various control methods |
| Standard Dbi Ignition Systems | plug-in rectifier unit for standard DBI ignition systems |
| Throttle Valve Regulation | Regulation by means of a throttle valve |
All specifications
| Max. inlet pressure | 60 mbar |
|---|---|
| Connection thread | Flanged connection |
| Supply voltage | 24 V |
| Coil voltage type | AC |
| Actuator type | Solenoid |
| Control features | electronic two-level regulator |
| Gas type | natural and liquefied gas |
| Operating voltage | 24 V |
| Housing type | standard housing |
| Diaphragm diameter | 2.8 mm |
| Pilot gas connection diameter | 4 mm |
| Inlet and outlet diameter | 18.6 mm |
| Ambient temperature | 0–70 °C |
| Softlite technology | Smooth and safe ignition |
| Design features | Positive feedback system |
| Two electrical devices | Two electrical devices |
| Pressure drop | 5 mbar |
| Valve type | pressure relief valve |
| Built-in valve | two valves (1st and 2nd) |
| Included components | VK8115V1036 valve and ignition regulator |
| Leakage requirements | EN126 |
| Nominal inlet gas pressure | 25 mbar |
| Pressure sensor pipe diameter | 0.5 inch |
| Operating position | upright |
| Maximum inlet pressure | 60 mbar |
| Maximum operating pressure | 60 mbar |
| Catalogue article numbers | 534.331.090 |
| Regulation of the mixture of gas and air in a ratio of 1 | 1 |
| Ambient pressure | 1013 mbar |
| Built-in filter | yes |
| Optional output filter | yes |
| Ignition electronics compatibility | various ignition regulators except S4565/S4585 |
| Throttle valve regulation | yes |
| Input screen | on the input side |
| Pressure relief valve | yes |
| Filter cleaning | not intended for cleaning |
| Side socket | yes |
| Output pressure stability | stable output pressure |
| Reliability | reliable in operation |
| Pressure servo controller | high-tech pressure servo controller |
| Ignition regulator exception | S4565/S4585 series regulators |
| Flanged connections | flanged connections |
| Control type | pressure control using a servo |
| connection_type | flanged |
| Back pressure (1st valve) | 10 mbar |
| Frequency | 50 Hz |
| Flow capacity | 3.2 m³/h |
Part numbers
| SKU | VK8115V1036U |
|---|---|
| Additional article | 534.331.090 |
| Model | VK8115V1036 |
