Honeywell Gas valve V4600C1086U

SKU V4600C1086U Model V4600C1086 Brand Honeywell

Photos

Key specifications

Max. inlet pressure	60 mbar
Supply voltage	220–240 V
Output pressure range	2.5–20 mbar
Ambient temperature	0–70 °C
Safety feature	thermoelectric protection
Actuator type	Fast opening electromagnet
Gas type	natural and liquefied gas
Softlite technology	Softlite diaphragm
Application	Burner systems
Pilot type	standing pilot
Coil replaceability	Replaceable separately from valve body
Voltage	230 V
Frequency	50–60 Hz

all specifications (13) ↓

282.30 EUR

256.64EUR

in stock · 1

incl. 21% VAT · 212.10 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

The Honeywell V4600C1086U is a gas valve intended for burner systems. It operates with a supply voltage of 220–240 V at 50–60 Hz. Maximum inlet pressure is 60 mbar, and the outlet pressure can be adjusted from 2.5 to 20 mbar, accommodating natural and liquefied gas. The valve uses a fast-opening electromagnet and incorporates a Softlite diaphragm. Safety is provided by thermoelectric protection with a standing pilot. The coil is replaceable separately from the valve body.

Further details

Connection Thread	internal thread 1/2" x 1/2" BSP
Operating principle	Opens on command from burner control; gas pressure switch confirmation required

Choosing and fitting

When replacing a valve of this kind, note the connection size and coil voltage of the existing installation to ensure the new part matches. The coil is often replaceable separately from the valve body, allowing it to be swapped independently if needed. Before fitting, verify that the valve's specifications align with the system's requirements.

Signs of failure

Typical failures include coil burnout, a leaking seat, drifting outlet pressure, and a seized servo regulator. Symptoms may involve intermittent operation or the safety system shutting off fuel supply. Check the coil, inspect the seat for leaks, and verify outlet pressure to diagnose the issue.

All specifications

Max. inlet pressure	60 mbar
Supply voltage	220–240 V
Output pressure range	2.5–20 mbar
Ambient temperature	0–70 °C
Safety feature	thermoelectric protection
Actuator type	Fast opening electromagnet
Gas type	natural and liquefied gas
Softlite technology	Softlite diaphragm
Application	Burner systems
Pilot type	standing pilot
Coil replaceability	Replaceable separately from valve body
Voltage	230 V
Frequency	50–60 Hz

Part numbers

SKU	V4600C1086U
Additional article	534.322.011
Model	V4600C1086
Superseded number	V4600
