Honeywell Gas solenoid valve VK4105N5016U
SKU VK4105N5016U
Model VK4105N5016
Brand Honeywell
Photos
Key specifications
| Inlet and outlet diameter | 18.6 mm |
|---|---|
| Nominal inlet gas pressure | 25 mbar |
| Pressure sensor pipe diameter | 0.5 inch |
| Ambient pressure | 1013 mbar |
| Diaphragm diameter | 2.8 mm |
| Pilot gas connection diameter | 4 mm |
| Operating position | upright |
| Built-in filter | built-in fine-mesh filter |
| Valve closing force variants | b+j, b+c, b +b |
| connection_type | flanged connection |
| Housing type | classic body |
| Control features | two-level electric regulator |
| Throttle valve regulation | alternative throttling valve control |
| Softlite technology | softlite system for soft ignition |
| Regulation of the mixture of gas and air in a ratio of 1 | 1 |
| Smooth regulation with amplification | stepless regulation with amplification |
| Valve type | gas solenoid valve |
| Configurable options | variety of customizable options |
168.52 EUR
153.20EUR
in stock · 12
incl. 21% VAT · 126.61 EUR excl. VAT · shipping calculated at checkout
- Worldwide shipping from stock
- Original manufacturer part
- Dispatch within 24 h for stocked items
Description
This gas solenoid valve has a classic body, uses flanged connections, and must be installed upright. It includes a built-in fine-mesh filter and a 2.8 mm diaphragm. This model offers a two-level electric regulator, alternative throttling valve control, Softlite soft-ignition system, 1:1 gas/air ratio regulation, and stepless regulation with amplification. The nominal inlet pressure is 25 mbar at 1013 mbar ambient pressure. The inlet and outlet diameter is 18.6 mm, the pressure sensor pipe is 0.5 inch, and the pilot gas connection is 4 mm. Available with closing-force variants b+j, b+c, and b+b and a variety of customizable options.
Further details
| Control Type | pressure regulation through the use of servo |
|---|---|
| Electrical Connection | connector to ignition regulator or plug-in rectifier unit |
| Gas-air ratio control in a ratio of 1 | 1: The ability to fine-tune the gas-air ratio ensures optimal mixing, which contributes to efficient combustion |
| Included Components | VK4105N5016U valve and special ignition regulator |
| Mounting Feature | holes at the bottom for mounting |
| Optional Output Filter | additional output filter can be added |
| Power supply | When the power supply is supplied, the system is activated. The gas begins to flow into the pressure servo controller |
| Side gas outlet | available as a variant (for main and pilot burner) |
| Support pressure regulation through the use of servo | This function allows you to fine-tune the gas pressure according to the requirements of a particular process |
Choosing and fitting
Gas solenoid valves of this type are selected by matching the flange connection size, the closing variant (b+j, b+c, b+b), and the electrical connection type to the existing system. Before ordering, measure the mounting dimensions and confirm whether a side gas outlet is present; if so, it can only be used with a flanged burner manifold. The valve body must be installed upright and secured via the mounting holes on the bottom.
All specifications
| Inlet and outlet diameter | 18.6 mm |
|---|---|
| Nominal inlet gas pressure | 25 mbar |
| Pressure sensor pipe diameter | 0.5 inch |
| Ambient pressure | 1013 mbar |
| Diaphragm diameter | 2.8 mm |
| Pilot gas connection diameter | 4 mm |
| Operating position | upright |
| Built-in filter | built-in fine-mesh filter |
| Valve closing force variants | b+j, b+c, b +b |
| connection_type | flanged connection |
| Housing type | classic body |
| Control features | two-level electric regulator |
| Throttle valve regulation | alternative throttling valve control |
| Softlite technology | softlite system for soft ignition |
| Regulation of the mixture of gas and air in a ratio of 1 | 1 |
| Smooth regulation with amplification | stepless regulation with amplification |
| Valve type | gas solenoid valve |
| Configurable options | variety of customizable options |
Part numbers
| SKU | VK4105N5016U |
|---|---|
| Additional article | 534.331.109 |
| Model | VK4105N5016 |
