Honeywell Gas valve VR4615VB1022U

SKU VR4615VB1022U Model VR4615VB1022 Brand Honeywell

Photos

Key specifications

Max. inlet pressure	60 mbar
Connection thread	flange
Solenoid configuration	two electrical actuators
Safety feature	valve closes on power failure
Diaphragm diameter	2.8 mm
Inlet and outlet diameter	23 mm
Regulator standard	v4346a 1006 (45.801.155-001)
Leakage requirements	according to en126
Nominal inlet gas pressure	25 mbar
Pressure sensor pipe diameter	0.5 inch
Operating position	vertical
Maximum inlet pressure	60 mbar
Maximum operating pressure	60 mbar
Ambient pressure	1013 mbar
Built-in filter	internal fine-mesh filter
Throttle valve regulation	with throttle
Design features	positive feedback system
Input screen	on the input side
Two electrical devices	two electrical actuators
Coil connection	top connection
Control type	positive feedback system
Barcode standard	alternating 2/5, DIN EN 801
Pressure test points	pressure testing nipple
Back pressure (1st valve)	50 mbar
Mounting feature	two threaded mounting holes
Optional output filter	output mesh filter on request
Pressure measuring fittings	outer diameter 9 mm
Regulator spring lock	regulator spring can be locked
Ignition systems supported	dsi, hsi or ip
Power options	mains or low-voltage
Flow indication	m3/h
Pressure drop	10 mbar
Maximum air pressure (before ignition)	8 mbar
Maximum air pressure (after ignition)	20 mbar
Output aperture diameter	2.8 mm
connection_type	flanged connection
Actuator type	two-position tracking type
Electrical connection	DIN connector, AMP compatible
Pressure measuring points	on inlet and outlet sides
Compression fitting	present
Pilot flow	present
Flow capacity	8.1 m³/h
Certification	CE

all specifications (43) ↓

324.68 EUR

295.16EUR

in stock · 6

incl. 21% VAT · 243.93 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This gas valve (Honeywell VR4615VB1022U) has flanged connections with a 23 mm diameter. It regulates gas flow in heating systems and is compatible with DSI, HSI, and IP ignition systems. The valve works at a nominal inlet pressure of 25 mbar and a maximum pressure of 60 mbar, and has a flow capacity of 8.1 m³/h at a 10 mbar pressure drop. It employs two electrical actuators and closes on power failure, and features an internal fine-mesh filter, throttle, and pressure testing nipple. It is CE certified, complies with EN126, and is intended for Wolf equipment.

Further details

Application	domestic heating systems, heaters, boilers and water heaters
Closing Variants	b+ b, b + j, b+c, a+ j and a+c
Control Features	two-level regulation and modulation of gas flow
Gas Type	petroleum gases mfd group a (g110), mfd group b (g 120), natural gas h (g 20), natural gas l (g25) and liquefied gas lp (g30)
Operating Principle	automatic control of gas outlet pressure using built-in positive feedback system
Output Pressure Stability	stable outlet pressure, regardless of changes in inlet pressure
Valve Classification	safety valve class a/b, main valve class b/c/j

Fits equipment

Wolf

All specifications

Max. inlet pressure	60 mbar
Connection thread	flange
Solenoid configuration	two electrical actuators
Safety feature	valve closes on power failure
Diaphragm diameter	2.8 mm
Inlet and outlet diameter	23 mm
Regulator standard	v4346a 1006 (45.801.155-001)
Leakage requirements	according to en126
Nominal inlet gas pressure	25 mbar
Pressure sensor pipe diameter	0.5 inch
Operating position	vertical
Maximum inlet pressure	60 mbar
Maximum operating pressure	60 mbar
Ambient pressure	1013 mbar
Built-in filter	internal fine-mesh filter
Throttle valve regulation	with throttle
Design features	positive feedback system
Input screen	on the input side
Two electrical devices	two electrical actuators
Coil connection	top connection
Control type	positive feedback system
Barcode standard	alternating 2/5, DIN EN 801
Pressure test points	pressure testing nipple
Back pressure (1st valve)	50 mbar
Mounting feature	two threaded mounting holes
Optional output filter	output mesh filter on request
Pressure measuring fittings	outer diameter 9 mm
Regulator spring lock	regulator spring can be locked
Ignition systems supported	dsi, hsi or ip
Power options	mains or low-voltage
Flow indication	m3/h
Pressure drop	10 mbar
Maximum air pressure (before ignition)	8 mbar
Maximum air pressure (after ignition)	20 mbar
Output aperture diameter	2.8 mm
connection_type	flanged connection
Actuator type	two-position tracking type
Electrical connection	DIN connector, AMP compatible
Pressure measuring points	on inlet and outlet sides
Compression fitting	present
Pilot flow	present
Flow capacity	8.1 m³/h
Certification	CE

Part numbers

SKU	VR4615VB1022U
Additional article	534.331.098
Model	VR4615VB1022
Type designation	V4346A 1006
Type designation	45.801.155-001
