Kromschroder Gas relief safety valve VSBV 25TN40-0 84583070

SKU 84583070 Model VSBV 25TN40-0 Brand Kromschroder

Photos

Key specifications

Nominal diameter (DN)	25 mm
Max. inlet pressure	4000 mbar
Connection thread	Rp 1"
Maximum working pressure	4 bar
Operating position	upright
Valve type	relief safety valve
Compliance standard	European safety standards
Country of origin	Germany
Certification	European safety standards
Setting range	20–500 mbar

all specifications (10) ↓

1155.04 EUR

1050.04EUR

in stock · 2

incl. 21% VAT · 867.80 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This relief safety valve is designed for gas systems to protect against overpressure. It has a nominal diameter of 25 mm and a Rp 1" connection thread. The valve operates within a pressure range of 20 to 500 mbar and has a maximum working pressure of 4 bar. It is suitable for upright installation and is manufactured in Germany. The valve complies with European safety standards.

Further details

Maintenance requirement	Periodic inspection recommended to verify seat is clean and valve opens at correct pressure without leaking
Operating principle	Automatically relieves excess pressure from fast-closing solenoid valves or gas creep from pressure regulators
Protection function	Protects burner control, gas valve, and other components from overpressure
Purpose	relief of short-term pressure surges and gas creep
Purpose	relief of short-term pressure surges and gas creep

Choosing and fitting

Relief safety valves of this kind are chosen by set pressure, connection size, and body material; the set pressure may be adjustable or factory-set and is usually stated on the label. Before ordering, confirm the connection thread and the pressure setting from the existing valve. Install the valve upright, and route the vent line safely outdoors in accordance with applicable standards. The valve is not a shut-off or metering device; it acts independently of the burner control.

Signs of failure

Typical failure involves contamination on the seat causing leakage, or the valve opening at an incorrect pressure. This may be noticed as gas odor or unstable downstream pressure. Regular inspection should confirm the seat is clean and the valve opens at the correct pressure without leaking.

All specifications

Nominal diameter (DN)	25 mm
Max. inlet pressure	4000 mbar
Connection thread	Rp 1"
Maximum working pressure	4 bar
Operating position	upright
Valve type	relief safety valve
Compliance standard	European safety standards
Country of origin	Germany
Certification	European safety standards
Setting range	20–500 mbar

Part numbers

SKU	84583070
Additional article	624.334.025
Model	VSBV 25TN40-0
