Kromschroder Gas valve CG30R03VW5CWZZ 84769505

SKU 84769505 Model CG30R03VW5CWZZ Brand Kromschroder

Photos

Key specifications

Supply voltage	230 V
Ambient temperature	-10–60 °C
Maximum excess pressure	360 mbar
Weight	4300 g
Ingress protection	IP 54
Voltage	230 V
Net weight	4.3 kg

all specifications (7) ↓

1912.65 EUR

1738.77EUR

in stock · 13

incl. 21% VAT · 1437.00 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

This gas valve is used for gas flow regulation and safety shut-off in industrial burner and boiler systems. It operates on a 230 V supply and can withstand a maximum excess pressure of 360 mbar. The ambient temperature range is from -10 to +60 °C. The valve has an ingress protection rating of IP 54 and a net weight of 4.3 kg (4300 g).

Further details

Dimensions	18×18×35.3 cm
Protection rating	IP 54

All specifications

Supply voltage	230 V
Ambient temperature	-10–60 °C
Maximum excess pressure	360 mbar
Weight	4300 g
Ingress protection	IP 54
Voltage	230 V
Net weight	4.3 kg

Part numbers

SKU	84769505
Additional article	624.322.137
Model	CG30R03VW5CWZZ
