Kromschroder Gas solenoid valve VGP10R02W6 85293104

The Kromschroder VGP10R02W6 is an electromagnetic shut-off gas valve with a nominal diameter of 10 mm and a Rp 3/8" connection thread. It operates at a supply voltage of 230 V and 50 Hz, with a maximum inlet pressure of 200 mbar. The valve is normally closed and features fast opening and closing, meeting Class A certification per EN 161. It is manufactured in Germany and is an original spare part, with replaceable coils available in 230 V or 24 V AC/DC versions. This compact valve is designed for automatic gas shut-off in burner and boiler systems.

When selecting a replacement gas solenoid valve of this type, ensure the connection thread size (e.g., Rp 3/8") and nominal diameter match the existing piping. Verify the supply voltage and frequency (e.g., 230 V, 50 Hz) and the maximum inlet pressure rating to suit the system. The valve's function (normally closed, fast opening/closing) must be compatible with the burner control sequence. Installation involves threaded connections and electrical wiring; the coil can be replaced separately if needed.

Common failure modes for gas solenoid valves of this kind include coil burnout, leaking valve seats, and sticking due to debris. Symptoms may include the burner failing to ignite, gas flow continuing when the valve should be closed, or erratic operation. Check the coil continuity, valve seat condition, and ensure the inlet pressure is within the rated range.
