Kromschroder Gas solenoid valve VGP15R02W6Z 85294103

The Kromschroder VGP15R02W6Z is a single solenoid gas valve with Rp 1/2 connection thread, designed for automatic opening and closing of gas supply in burners and boilers. It operates at 230 V supply voltage and features a replaceable coil. This CE-certified valve is manufactured in Germany and provides fast response for gas control applications.

When selecting a replacement gas valve of this type, confirm the connection size (Rp 1/2 to 2 or flanged) and coil voltage (230 V or 24 V AC/DC) to match the existing system. Also verify the valve function—single or double solenoid, slow opening, or servo-regulated—to ensure compatibility with the burner control sequence. The coil is often replaceable separately, allowing valve restoration without removing the entire assembly from the gas train.

Typical failures include coil burnout, leaking seat, drifting outlet pressure, and seized servo regulator. Symptoms may include failure to open or close, gas leakage, or unstable burner operation. Check the coil condition and seating surfaces, and verify outlet pressure with a test point downstream.
