Kromschroder Flow adjusting cock GEHV15 03152260
SKU 03152260
Model GEHV15
Brand Kromschroder
Photos
Key specifications
| Nominal diameter (DN) | 15 mm |
|---|---|
| connection_type | threaded |
| Weight | 280 g |
| Certification | DIN-DVGW |
| Ambient temperature, max | 60 °C |
| Type of cock | adjusting, manual (flow adjusting cock) |
| Working temperature min | -15 °C |
| Control | handwheel with adjusting scale |
| Visual indication | scale on handwheel |
| Sealing check | perform tightness test after mounting |
157.48 EUR
143.16EUR
in stock · 5
incl. 21% VAT · 118.31 EUR excl. VAT · shipping calculated at checkout
- Worldwide shipping from stock
- Original manufacturer part
- Dispatch within 24 h for stocked items
Description
The Kromschroder GEHV15 flow adjusting cock (SKU 03152260) is a manual needle valve for precise adjustment of gas or air flow in burner fuel supply systems. It has a nominal diameter of 15 mm, a threaded connection, and operates within a temperature range of -15 °C to +60 °C. The cock is controlled via a handwheel with an adjusting scale for visual position indication, and it weighs 280 g. It is certified to DIN-DVGW for gas operation.
Further details
| Application | gas supply systems of industrial burners, boilers, furnaces and heat generators |
|---|---|
| Compatibility | used in gas supply systems of industrial burners, boilers, furnaces and heat generators |
| Operation check | operate through full range to verify smooth movement and proper seating |
Choosing and fitting
Parts of this type are selected by connection size and maximum operating pressure. Confirm the thread type and overall length match existing pipework. Install with the flow direction arrow (if marked) pointing toward the burner, and after mounting, perform a tightness test with the burner isolated.
All specifications
| Nominal diameter (DN) | 15 mm |
|---|---|
| connection_type | threaded |
| Weight | 280 g |
| Certification | DIN-DVGW |
| Ambient temperature, max | 60 °C |
| Type of cock | adjusting, manual (flow adjusting cock) |
| Working temperature min | -15 °C |
| Control | handwheel with adjusting scale |
| Visual indication | scale on handwheel |
| Sealing check | perform tightness test after mounting |
Part numbers
| SKU | 03152260 |
|---|---|
| Additional article | 624.439.060 |
| Model | GEHV15 |
