ACV Heating element 10800084

ACV Heating element 10800084 is a 6 kW, 400 V three-phase heating element designed for use in ACV boilers. It is compatible with ACV e-tech w 60, ACV e-tech p 65, ACV compact 60, ACV compact 75, and ACV e-tech 75 twin models. This immersion heater converts electrical energy into heat for boiler systems.

When selecting a replacement heating element of this type, verify that the power output, voltage, and mechanical fixing (thread size or flange) match the original. Measure the immersion length and ensure the sheath material is compatible with the system's water chemistry. Confirm the electrical connections are rated for the current and use a dedicated thermostat and high-limit safety device.

Common failures include element burnout due to scale buildup or dry firing, leading to insufficient heating or no heat output. Check for tripped circuit breakers, blown fuses, or visible damage to the element. Test for leakage current and verify continuity with a multimeter.
