Brahma Ignition transformer TC2LTPSF 15910653

The Brahma Ignition transformer TC2LTPSF 15910653 is a compact electronic ignition transformer designed for use in gas and liquid fuel burners. It operates on a supply voltage of 220–240 V at 50 Hz, with a secondary voltage of 12 kV and a secondary current of 55 mA. The transformer has a power consumption of 30 W and a duty cycle of 100%, allowing continuous operation. It features two poles and weighs 0.42 kg net. The recommended spark distance is 3–5 mm, and the maximum ignition cable length is 1.5 m, with a standard power cable length of 560 mm. The protection rating is IP00.

When selecting an ignition transformer of this type, ensure the supply voltage, frequency, and secondary voltage match the burner's requirements. The mounting configuration and connection system (e.g., number of contacts, type of high-voltage connection) must be compatible with the existing setup. Measure the physical dimensions and weight to confirm fit, and verify the recommended spark distance and cable lengths for proper installation.

Common failure modes for ignition transformers include internal short circuits, open circuits, or insulation breakdown, often due to moisture, overheating, or voltage surges. Symptoms may include failure to ignite, weak or intermittent spark, or tripping of the burner controller. Check for visible damage, measure secondary voltage with a suitable probe, and inspect the high-voltage cable and connections for wear or corrosion.
