Brahma Ignition transformer TC2STCA 15911164
SKU 15911164
Model TC2STCA
Brand Brahma
Photos
Key specifications
| Supply voltage | 110-120 V 50/60 Hz |
|---|---|
| Secondary voltage | 24 kV |
| Construction type | high-frequency electronic |
| Operating temperature | -10–60 °C |
| Weight | 420 g |
| Maximum length of ignition cable with integrated electronic ignition | 1.5 m |
| Ingress protection | IP00 |
| Number of contacts | 2 |
| Peak current (mA) | 55 mA |
| Recommended spark distance | 3–5 mm |
| Standard power cable length | 560 mm |
| Output voltage frequency | 6–10 kHz |
| Core material | ferritic |
| Built-in filter | available as integrated EMC filter |
| External filter not required | No additional external filters required |
| Electromagnetic interference protection | filter to reduce electromagnetic interference |
| High efficiency | high efficiency |
| Safety feature | built-in short circuit protection |
| Mounting and connecting systems | various mounting and connecting systems |
| Design features | compact dimensions |
| Ignition system type | high-frequency electronic |
| Power consumption | 55 W |
| Frequency | 50–60 Hz |
| Ambient temperature, max | 60 °C |
89.44 EUR
81.31EUR
in stock · 2
incl. 21% VAT · 67.20 EUR excl. VAT · shipping calculated at checkout
- Worldwide shipping from stock
- Original manufacturer part
- Dispatch within 24 h for stocked items
Description
This ignition transformer supplies high-voltage ignition for gas and oil burners. It operates from a 110–120 V AC supply at 50/60 Hz, consuming 55 W, and delivers a secondary voltage of 24 kV at an output frequency of 6–10 kHz with a peak current of 55 mA. The device uses a high-frequency electronic circuit on a ferritic core, has two contacts, and is rated for operation from –10 to 60 °C. It includes an integrated EMC filter, built-in short-circuit protection, and a recommended spark distance of 3–5 mm; its maximum ignition cable length is 1.5 m and its standard power cable is 560 mm long. The housing is rated IP00 and the weight is 420 g.
Further details
| Application | gas burners, liquid fuel burners, domestic/commercial/industrial |
|---|---|
| Certification | LVD 73/23/EEC, EN 61558-1:1997+A1:1998+A11:2003, EN 61558-2-3:2000 |
| Fuel Type | gas, light and heavy liquid fuels |
All specifications
| Supply voltage | 110-120 V 50/60 Hz |
|---|---|
| Secondary voltage | 24 kV |
| Construction type | high-frequency electronic |
| Operating temperature | -10–60 °C |
| Weight | 420 g |
| Maximum length of ignition cable with integrated electronic ignition | 1.5 m |
| Ingress protection | IP00 |
| Number of contacts | 2 |
| Peak current (mA) | 55 mA |
| Recommended spark distance | 3–5 mm |
| Standard power cable length | 560 mm |
| Output voltage frequency | 6–10 kHz |
| Core material | ferritic |
| Built-in filter | available as integrated EMC filter |
| External filter not required | No additional external filters required |
| Electromagnetic interference protection | filter to reduce electromagnetic interference |
| High efficiency | high efficiency |
| Safety feature | built-in short circuit protection |
| Mounting and connecting systems | various mounting and connecting systems |
| Design features | compact dimensions |
| Ignition system type | high-frequency electronic |
| Power consumption | 55 W |
| Frequency | 50–60 Hz |
| Ambient temperature, max | 60 °C |
Part numbers
| SKU | 15911164 |
|---|---|
| Additional article | 246.820.094 |
| Model | TC2STCA |
