Brahma Ignition transformer TR2/A 15909032

SKU 15909032 Model TR2/A Brand Brahma

Photos

Key specifications

Secondary voltage	15 kV
Poles / outlets	1
Maximum length of ignition cable with integrated electronic ignition	1 m
Recommended spark distance	2–4 mm
Ingress protection	IP00
Mounting feature	any position
Application	atmospheric gas burners
Fuel	gas
Duty cycle	100%
Net weight	0.055 kg
Power consumption	2.5 W

all specifications (11) ↓

83.37 EUR

75.79EUR

in stock · 12

incl. 21% VAT · 62.64 EUR excl. VAT · shipping calculated at checkout

Worldwide shipping from stock
Original manufacturer part
Dispatch within 24 h for stocked items

Description

The Brahma TR2/A ignition transformer (SKU 15909032) supplies a secondary voltage of 15 kV for spark ignition in atmospheric gas burners. It has a single-pole output and a 100% duty cycle, with power consumption of 2.5 W. The transformer is rated for a maximum ignition cable length of 1 m and a recommended spark distance of 2–4 mm. Its housing provides IP00 protection and permits installation in any position. Net weight is 0.055 kg. It is intended for gas-fired heating equipment.

All specifications

Secondary voltage	15 kV
Poles / outlets	1
Maximum length of ignition cable with integrated electronic ignition	1 m
Recommended spark distance	2–4 mm
Ingress protection	IP00
Mounting feature	any position
Application	atmospheric gas burners
Fuel	gas
Duty cycle	100%
Net weight	0.055 kg
Power consumption	2.5 W

Part numbers

SKU	15909032
Additional article	246.820.091
Model	TR2/A
