Fida Ignition transformer ECSB34

The Fida Ignition transformer ECSB34 is an electronic ignition transformer with a supply voltage of 230–240 V and a secondary voltage of 26 kV. It provides a secondary current of 30 mA and operates at a frequency of 50–60 Hz. This transformer has a duty cycle of 100%, one pole, and is certified to EN 61558-2-3. It features protection against moisture and dust, a compact size for easy installation, and silicone insulation on the ignition cable. This item is made in Italy and fits the Fida 26/30 IS.

When selecting an ignition transformer of this type, ensure the primary voltage matches the burner control output, and the secondary voltage and current are sufficient for the electrode gap and fuel. Check that the mounting arrangement, terminal type, and connector pattern are compatible with the existing wiring. The ignition cable must have silicone insulation to withstand high voltage and heat.

Typical failures include cracked or hardened ignition cables that leak spark to earth, which can mimic a faulty transformer. Equipment may fail to ignite or exhibit intermittent sparking. Check the cable insulation and transformer output for signs of wear or damage.
