Fida Ignition transformer TE061D

The Fida Ignition transformer TE061D is a component designed for use with the Fida Compact 6/25PM burner. It operates on a supply voltage of 230 V and a frequency of 50–60 Hz, providing a secondary current of 25 mA. This transformer is active only during the ignition phase, as it has 1 pole and is not used for continuous operation. Its function is to generate the high voltage necessary for creating a spark at the ignition electrode.

When selecting a replacement ignition transformer of this kind, verify that the primary voltage (e.g., 230 V) matches the burner's electrical supply. Check the secondary current and voltage ratings to ensure they are compatible with the ignition electrode requirements. Confirm the physical mounting arrangement and the type of high-voltage connector, as these can vary between models. Always compare the dimensions and terminal configuration with the original part before ordering.

Typical failures of ignition transformers include internal short circuits or open windings, which result in no spark at the electrode. A cracked or hardened high-voltage cable can cause spark leakage to ground, leading to weak or intermittent ignition. If the burner fails to ignite or the flame is unstable, inspect the transformer and its cable for signs of damage or wear.
