ACV Kit electrode 10800313

The ACV Kit electrode 10800313 is a replacement electrode kit designed for use in ACV HM70-85-120TC boilers, as well as CA 250 Comfort and CA 300 Comfort models. It belongs to the ionization and ignition electrodes category, serving as a consumable component that operates directly in the flame zone. The kit is resistant to soot buildup, which helps maintain consistent performance. This electrode kit is intended to match the original part number for proper fit and function.

When selecting a replacement electrode of this type, critical parameters include electrode length and bend, insulator diameter, spark gap, mounting flange design, and the burner series for which the electrode was originally shaped. To ensure compatibility, remove the existing electrode assembly and compare the rod profile, ceramic diameter, mounting plate, and the distance from the mounting face to the tip. Verify the exact function and number of electrodes in the kit against the burner's wiring diagram or original part.

Common failure modes for electrodes of this kind include eroded or blunted tips, cracked ceramic insulators, soot buildup that bridges the gap, and a drifting spark gap that lengthens ignition time. When these issues occur, the equipment may experience unreliable ignition or flame sensing, leading to burner lockouts or failure to start. Regular inspection of the electrode condition is standard practice during burner servicing to detect these problems early.
