Brahma Electrode K3,0 ALV 10-120. T4 300 12431616

Brahma Electrode K3,0 ALV 10-120. T4 300, SKU 12431616, is an ignition and ionization electrode for gas burners. It has a total length of 445 mm, with an ignition rod diameter of 3 mm and a rod length of 300 mm. The ceramic insulation is 10 mm in diameter and 120 mm long. This electrode is resistant to soot, but its ceramic insulator is prone to cracking.

When selecting a replacement electrode of this type, verify the total length, rod diameter, and insulator dimensions against the existing part. Ensure the electrode's bend angle, spark gap, and mounting flange configuration match the burner. The electrode must be compatible with the specific burner series and the ignition cable plug size (typically 4 mm). Always compare the physical fit before ordering.

Typical failures include erosion of the electrode tip, cracking of the ceramic insulator, sooting that can short the spark, and a drifting spark gap. These issues can extend ignition time or prevent flame detection, leading to burner lockout. Check the electrode for visible damage, soot buildup, and proper spark gap.
