Kromschroder Adapter set 74921674
SKU 74921674
Brand Kromschroder
Photos
Key specifications
| Compatibility series | BVA/G |
|---|---|
| Catalogue article numbers | 624.106.017 |
| Mechanical strength | positive torque transmission without slippage |
214.53 EUR
195.03EUR
in stock · 1
incl. 21% VAT · 161.18 EUR excl. VAT · shipping calculated at checkout
- Worldwide shipping from stock
- Original manufacturer part
- Dispatch within 24 h for stocked items
Description
Kromschroder Adapter set 74921674 is a spare part for Kromschroder BVA/BVG butterfly valves. It is used to mount actuators with a square shaft on these valves when the standard IC 20/IC 40 actuators are not used. The adapter set ensures positive torque transmission without slippage, providing a secure connection. It is compatible with the BVA/G series and corresponds to article number 624.106.017.
Further details
| Advantages | original kit, reliable actuator installation, universal solution, ease of installation, enhanced safety |
|---|---|
| Compatibility check | verify actuator output shaft matches square bore and bolt-hole pattern aligns |
| Installation | easy installation, ability to use when mounting outside standard actuator series |
| Installation notes | tighten fixing screws to manufacturer's specified torque |
| Purpose | mounting butterfly valves with actuators other than standard IC 20/IC 40 series |
| Safety | correct actuator installation reduces risk of incorrect operation and eliminates valve misalignment |
| Safety note | ensure adapter does not introduce play affecting valve stroke limits |
| Selection criteria | shaft dimensions (square side length and length of engagement) and mounting pattern of actuator flange |
Choosing and fitting
Parts of this type are selected by matching the actuator's square shaft dimensions (side length and engagement length) and the valve's mounting pattern. Verify that the actuator output shaft fits the adapter's square bore and that the bolt-hole pattern aligns with the valve housing. Ensure the adapter does not introduce play that could affect valve stroke limits. Tighten all fixing screws to the manufacturer's specified torque.
Fits equipment
Kromschroder BVA/BVG butterfly valves
All specifications
| Compatibility series | BVA/G |
|---|---|
| Catalogue article numbers | 624.106.017 |
| Mechanical strength | positive torque transmission without slippage |
Part numbers
| SKU | 74921674 |
|---|---|
| Additional article | 624.106.017 |
